JLG 110HXER ANSI Parts Manual User Manual
Page 40
2-4
3120637
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
54
Fastener Options:
1
0741608
110HX (Screw, Flathead 3/8”-16NC x 1”)
0641608
110HXER (Bolt 3/8”-16NC x 1”)
55
Lockwasher 3/8” Options:
A/R
Not Required
110HX
0
4761600
110HXER
3
56
Pin Options:
1
3421561
110HX
3420085
110HXER
57
Pin, Cotter 3/16” x 2 1/2” Options:
A/R
Not Required
110HX
0
3450610
110HXER
2
BEARING LUBE INSTALLATION
0239356
100HX & 110HX
Ref.
—
0239360
110HX+10 & 110HXER
Ref.
—
101
2160002
Fitting, Grease
3
2220124
Fitting
3
2750529
Hose (60" Length)
A/R
110HX
1
110HXER
2
2220261
Fitting, Coupling
A/R
110HX
1
110HXER
2
2220063
Fitting, 90º
2
2750527
Hose
2
2220063
Fitting, 90°
3
2750807
Hose
1
2200051
Plug 1/8”
1
0236629
HORIZONTAL CUTOUT LIMIT SWITCH INSTALLA-
TION (RIGHT SIDE)
Ref.
3
201
4360057
Switch, Limit
1
202
4761000
Lockwasher #10
2
203
0721014
Bolt #10-2NC x 1 3/4"
2
204
Not Used
205
0200048
Arm, Actuator
1
206
4460049
Connector
1
FIGURE 2-1. TURNTABLE, BOOM AND CUTOUT SWITCH INSTALLATIONS (4620038 TURNTABLE
MACHINES) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
