SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
174 4070991 Shim,.125 (S/N 47729 to Present) 1
175 3910804 Screw #8-32NC x 1/4” (S/N 47729 to Present) 6
CONTROL BOX ASSEMBLY (VARIABLE PARTS)
0860610 100HX Standard Machine With Deutz Engine/
4620044 & 4620078 Turntables Ref. 10
0860609 100HX Standard Machine With Ford LSG-423
Engine/4620044 & 4620078 Turntables Ref. 12
0860966 100HX Standard Machine With Ford LRG-423
Engine/4620078 Turntables Ref. 3
0239150 110HX Standard Machine With Deutz Engine/
4620038 Turntable Ref. 4
0860602 110HX Standard Machine With Deutz Engine/
4620044 & 4620078 Turntables Ref. 12
0239151 110HX Standard Machine With Ford LSG-423
Engine/4620038 Turntable Ref. 4
0860603 110HX Standard Machine With Ford LSG-423
Engine/4620044 & 4620078 Turntables Ref. 10
0860965 110HX Standard Machine With Ford LRG-423
Engine/4620078 Turntable Ref. 3
0239544 110HX 500 Lbs Capacity Machine With Deutz
Engine/4620038 Turntable Ref. 3
0860604 110HX 500 Lbs Capacity Machine With Deutz
Engine/4620044 & 4620078 Turntables Ref. 3
0239545 110HX 500 Lbs Capacity Machine With Ford LSG-
423 Engine/4620038 Turntable Ref. 3
0860605 110HX 500 Lbs Capacity Machine With Ford LSG-
423 Engine/4620044 & 4620078 Turntables Ref. 2
0860964 110HX 750 Lbs Capacity Machine With Deutz
Engine/4620078 Turntable Ref. 3
0239148 110HXER & 100HX+10 Standard Machine With
Deutz Engine/4620038 Turntable Ref. C
0860600 110HXER &100HX+10 Standard Machine With Deutz
Engine/4620044 & 4620078 Turntables Ref. 12
0239149 110HXER & 100HX+10 Standard Machine With Ford
LSG-423 Engine/4620038 Turntable Ref. C
0860601 110HXER & 100HX+10 Standard Machine With Ford
LSG-423 Engine/4620044 & 4620078 Turntables Ref. 13
0860967 110HXER & 100HX+10 Standard Machine With Ford
LRG-423 Engine/4620078 Turntable Ref. 5
201 Lid/Nameplate Options: 1
100HX:
3251919 Prior to May 1994
3252389 May 1994 to S/N 47729
3252654 S/N 47729 to Present
110HX:
3251856 Prior to May 1994
3252388 May 1994 to S/N 47729
3252652 S/N 47729 to Present
110HXER & 100HX+10:
3251857 Prior to May 1994
FIGURE 2-34. GROUND CONTROLS INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
