SECTION 4 - SKYWELDER™
4-2 – JLG Accessory Manual – 3124242
DESCRIPTION
Welder
The welder will be capable of TIG and Stick welding. This welder will be
capable at producing 200 Amps at 100% duty cycle or 250 Amps at 50%
duty cycle.
(see: Safety Precautions when performing TIG welding)
Generator Output
ANSI Specs:240V;60Hz; 3-Phase; 7.5kW and 240V/120V:60Hz; Single
Phase:6kW.
CE Specs: 400V; 50Hz; 3-Phase; 7.5kW and 220V; 50Hz; Single Phase;6kW.
Engine Speed of 1800 rpm +/- 10%.
Welding Accessories
The platform will provide provisions for storing 12 ft. welding leads consist-
ing of a clamp and a stinger. A fire extinguisher will also be provided.
ACCESSORY RATINGS
Table 1. - Welding Characteristics
Welding Mode Input Power Rated Output
Welding
Amperage
Range
Maximum Open
Circuit Voltage
Amps Input At Rated Load Output. 50/60 Hz
230 V 460 V 575 V KVA KW
Stick
(SMAW)
3- Phase
5 -250 Amp at 30V.
50% Duty Cycle
5-250Amp 80 VDC
30.5 14.7 11.6 11.7 8.6
200 Amp at 28V.
100% Duty Cycle 21.7 11.4 9.2 9.1 6.4
TIG (GTAW) 1 -Phase
200 Amp at 28V.
50% Duty Cycle
5-200 Amp 65 VDC
42.6 ------ ------ 9.8 6.5
150 Amp at 28V.
100% Duty Cycle 304 ------ ------ 6.9 4.4
