SECTION 2 - SKYPOWER™ (BELT DRIVEN)
3124242 – JLG Accessory Manual – 2-25
23 3311005 Locknut #10-24NC 2
24 0641618 Bolt 3/8”-16NC x 2 1/4" 1
25 3574163 Bracket, Relay Mounting 1
26 4060802 Guard, Switch 1
27 3740080 Relay 2
28 4360336 Switch, Toggle 1
29 4751000 Flatwasher #10 4
30 4711400 Flatwasher 1/4" Narrow A/R
31 4711500 Flatwasher 5/16” Narrow 10
32 4711600 Flatwasher 3/8” Narrow A/R
33 4711800 Flatwasher 1/2” Narrow 4
34 4761500 Lockwasher 5/16” 4
35 4791400 Starwasher 1/4” A/R
36 4922925 Harness, Generator 1
37 0641610 Bolt 3/8”-16NC x 1 1/4” 1
38 0721004 Screw #10-24NC x 1/2" 2
39 2820031 Heat Shrink A/R
40 3252764 Nameplate 1
41 1320318 Clamp, Hose A/R
42 4240018 Strap, Tie (Not Shown) A/R
43 to 45 Not Used
Note: Items #46 - #54 used on all installations except
#1001097512, #1001097583, #1001111910 & #1001112044. Ref.
46 0860038 Box, Switch 2
47 3910606 Screw #6-32NC x 3/8" 8
48 3960422 Gasket 2
49 Cover, Receptacle Options: 1
49A 4060700 Cover, Side Hinged
49B 1001110873 Cover, Top Hinged
50 Cover, Receptacle Options: 1
50A 4061043 Cover, Side Hinged
50B 1001110872 Cover, Top Hinged
51 4460071 Connector, Strain Relief A/R
52 4460346 Receptacle, Female (110-120V) 1
53 4460958 Receptacle, Female Twist-Lock (220-240V Single) 1
54 4460051 Connector, Strain Relief A/R
JUNCTION BOX ASSEMBLY Ref.
0861542 60Hz Specs Ref. D
0861567 50Hz Specs Ref. B
101 0861541 Box, Junction 1
102 Cable, Electrical 12/3 2 ft/.6m
1060494 60Hz Spec
Not Available 50Hz Spec (Supply Locally)
103 Cable, Electrical 10/3 2.5ft/.76m
1060708 60Hz Spec
Not Available 50Hz Spec (Supply Locally)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
