SECTION 2 - SKYPOWER™ (BELT DRIVEN)
2-2 – JLG Accessory Manual – 3124242
DESCRIPTION
This belt-driven generator supplies AC power to the platform to run tools,
lights, cutting and welding equipment through an AC receptacle. All power
regulation components are located in a watertight box that is connected by
cable to the generator. The generator supplies power when running at the
specified speed with the power switch on (switch is located on platform). A
three-pole, 30 Amp circuit breaker protects the generator from overload.
Generator Output
ANSI Specs:
240V;60Hz; 3-Phase; 7.5kW and 240V/120V:60Hz; Single Phase:6kW.
CE Specs:
3-phase, 240-volt, 7.5kw, 18.3-amps, 1.0-pf
1-phase, 240 volt, 6.0kw, 26-amps, 1.0-pf
1-phase, 120 volt, 6.0kw, 50-amps, 1.0-pf
Peak:
3-phase 8.5kw
1-phase 6.0kw
ACCESSORY RATINGS
SAFETY PRECAUTIONS
General
READ AND UNDERSTAND THE OPERATORS MANUAL FOR THE SPECIFIC JLG MODEL
BEING USED.
DO NOT OVER LOAD PLATFORM.
1. Make sure no personnel are beneath platform.
2. This factory installed option is available only on models specified.
3. Keep lanyard attached at all times.
4. Do not use electrical tools in extremely wet conditions.
5. Use correct voltage for tool being used.
6. Do not over load circuit.
Model Drive -Type Generator Speed
18RS/24RS/400S/450A
Series II
450AJ Series II/460SJ
510AJ/600A/600AJ
600S/600SC/600SJ
660SJ/660SJC
800A/800AJ/800S
860SJ/1100SJP/1200SJP
1250AJP/1350SJP/1500SJP
Belt-Drive/Pulley
3000rpm (50 Hz)
3600 rpm (60 Hz)
