SECTION 2 - SKYPOWER™ (BELT DRIVEN)
2-8 – JLG Accessory Manual – 3124242
19 Cont’d Use 2460048 Deutz Engine with 50Hz Generator (400S/460SJ/510AJ/
600A/600AJ/600S/600SC/600SJ/660SCJ/660SJ/800A/
800AJ/800S/860SJ) (was p/n 2460045 which included p/n
7024493 Replacement Generator Prior to
S/N 0300075304)
2460048 Deutz Engine with 60Hz Generator (450A Series II/450AJ
Series II/1100SJP/1200SJP/ 1250AJP/1350SJP)
2460048 Deutz Engine with 50Hz Generator (18RS/24RS/450A
Series II/450AJ Series II/1200SJP/ 1250AJP/1350SJP)
Use 70003631 Brushholder Assembly (Not Shown) (was p/n 7024484) 1
7024485 Breaker, Circuit 30Amp (Not Shown) 1
70001696 Boot, Breaker (was p/n 7024486 - Not Shown) 1
7027799 Block, Connection - 6 Position (Not Shown) 1
70002460 Nut, Brass (Attaches p/n 7027799 to Cover) (Not
Shown) 6
7026597 Connector, W/Lead (Not Shown) 1
7026188 Connector, Clamp (Not Shown) 1
See Note Panel, End (Not Shown)
(Note: Was p/n 70002255 - Use p/n 70004169 Kit as
replacement for Deutz Engine Machines &
p/n 70004170 for Caterpillar Engine Machines) 1
Stator Options (Not Shown): 1
70001969 2460050 Generator 1
70002088 2460048 Generator 1
70003451 1001119250 Generator 1
70001974 Decal - Terminal Connections (Not Shown) 1
70000863 Fan (Not Shown) 1
70002297 Stud (Not Shown) 4
70001100 Armature, Generator (Includes Radial Ball Bearing on
End with Brushes and Fan) 1
70001384 Bearing, Ball Radial 1
19A Use 70004171 Key (was p/n 7024561) 1
19B 70001966 Bearing, Radial Ball 1
19C 70001973 Decal - Warning Moving Parts 1
19D See Note Endbell, Brush Block
(Note: Was p/n 70001385 - Use p/n 70004169 Kit as
replacement for Deutz Engine Machines &
p/n 70004170 for Caterpillar Engine Machines) 1
19E 70001953 Endbell, Belt Tensioner 1
19F See Note Endbell, Shroud Assembly
(Note: Was p/n 70002290 - Use p/n 70004169 Kit as
replacement for Deutz Engine Machines &
p/n 70004170 for Caterpillar Engine Machines) 1
19G 70003708 Ring, Retaining (Internal) 1
19H 70003709 Ring, Retaining (External) 1
20 Bolt Options: A/R
Bolt 1/2”-13NC Options:
0641808 Caterpillar Engine (All except 1100SJP/1200SJP/
1250AJP/1350SJP/1500SJ) 3
0641810 Caterpillar Engine (1100SJP/1200SJP/1250AJP/
1350SJP/ 1500SJ Only) 2
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
