SECTION 5 - SKYCUTTER™
5-2 – JLG Accessory Manual – 3124242
DESCRIPTION
Plasma Cutter
The Plasma Cutter will be capable of cutting up to a thickness of 3/8 in.
metal. This cutter will be capable of producing 27A at 92 VDC @ 35% duty
cycle or 14A at 92 VDC @ 60% duty cycle.
Generator Output
ANSI Specs:240V;60Hz; 3-Phase; 7.5kW and 240V/120V:60Hz; Single
Phase:6kW.
CE Specs: 400V; 50Hz; 3-Phase; 7.5kW and 220V; 50Hz; Single Phase;6kW.
Engine Speed of 1800 rpm +/- 10%.
ACCESSORY RATINGS
Table 1. - Plasma Cutter Characteristics - P/N’s-4530024 and 4530025
Spec.
Rated Out-
put
115 V
(+/- 15%)
230 V
(+/- 15%)
115 V
KVA/KW
230 V
KVA/KW
Plasma
Gas
Plasma Gas
Flow/Pres-
sure
Rated Cut-
ting Capac-
ity @ 10 IPM
Max.
OCV
ANSI
P/N
4530024
Amperes Input @
Rated Output, 60 Hz,
Single-Phase
27 A @ 92
VDC @ 35%
Duty Cycle
28 max;
0.33*
14 max;
0.13*
3.32 KVA
3.25 KW
3.25 KVA
3.19 KW
Air or
Nitrogen
Only
4.5 CFM
(129 L/Min)
@ 60 PSI
(414 kpa)
3/8 in.
(10 mm)
288 VDC
14 A @ 92
VDC @ 60%
Duty Cycle
17 max;
0.30*
8.4 max;
0.13*
CE
P/N
4530025
Amperes Input @
Rated Output, 50 Hz,
Single-Phase
27 A @ 92
VDC @ 35%
Duty Cycle
27 max;
0.33*
13 max;
0.13*
3.11 KVA
3.09 KW
3.04 KVA
3.04 KW
Air or
Nitrogen
Only
4.5 CFM
(129 L/Min)
@ 60 PSI
(414 kpa)
3/8 in.
(10 mm)
288 VDC
14 A @ 92
VDC @ 60%
Duty Cycle
16 max;
0.33*
7.8 max;
0.17*
*While Idling.
Table 2. - Plasma Cutter Characteristics - P/N-1001098012
Spec. Rated Output
Amperes
Input @ Rated
Output, 60 Hz,
Single-Phase
KVA/KW Plasma Gas
Plasma Gas
Flow/Pressure
Rated Cutting
Capacity
@ 10 IPM
Max. OCV
120 Volts
±10%
(20A)
27 A @ 91 VDC
@ 20% Duty
Cycle
28.8 max;
0.30*
3.4 KVA
3.2 KW
Air or Nitrogen Only
@ 90 - 120 PSI
(621 - 827 kPa)
4.5 CFM
(129 L/Min)
@ 60 PSI
(414 kpa)
3/8 in.
(10 mm)
400 VDC
120 Volts
±10%
(15A)
20 A @ 88 VDC
@ 35% Duty
Cycle
20.6 max;
0.30*
2.5 KVA
2.3 KW
240 Volts
±10%
(27A)
27 A @ 91 VDC
@ 35% Duty
Cycle
13.9 max;
0.13*
3.3 KVA
3.0 KW
* While idling.
