SECTION 3 - SKYPOWER™ (HYDRAULICALLY DRIVEN)
3-6 – JLG Accessory Manual – 3124242
28 4360336 Switch, SPST 1
29 Connector Options: 2
4460051 60Hz Spec
Not Available 50Hz Spec (Supply Locally)
30 Terminal, Spade Options: 2
4460315 60Hz Spec
Not Available 50Hz Spec (Supply Locally)
31 Terminal, Receptacle Options: 1
4460346 60Hz Spec
Not Available 50Hz Spec (Supply Locally)
32 4460958 Receptacle, Twistlock Options: 1
4460958 60Hz Spec
Not Available 50Hz Spec (Supply Locally)
33 Valve, Generator Options: 1
4641239 Prior to S/N 70981
4641270 S/N 70981 to Present
34 4711400 Washer, 1/4" Narrow 8
35 Not Used
36 4740397 Spacer, Washer 1
37 4751500 Flatwasher 5/16" 13
38 4751600 Flatwasher 3/8" 4
39 4791400 Starwasher 1/4 2
40 Harness, Generator Cable Options: 1
4922796 1200SJP
4922795 1350SJP
41 to 42 Not Used
43 4751400 Flatwasher 1/4" (Prior to S/N 70981 Only) 1
44 Bolt Options: A/R
0641408 Bolt 1/4"-20NC x 1" (Prior to S/N 70981) 1
0641516 Bolt 5/16"-18NC x 2 " (S/N 70981 to Present) 3
45 Nut Options: A/R
2080044 Rivnut (Prior to S/N 70981) 1
3311505 Nut 5/16"-18NC (S/N 70981 to Present) 3
46 0100048 Grease, Dielectric (Not Shown) A/R
JUNCTION BOX ASSEMBLY Ref.
0861542 60Hz Specs Ref. C
0861567 50Hz Specs Ref. B
101 0861541 Box, Junction 1
102 Cable, Electrical 12/3 2 ft/.6m
1060494 60Hz Spec
Not Available 50Hz Spec (Supply Locally)
103 Cable, Electrical 10/3 2.5ft/.76m
1060708 60Hz Spec
Not Available 50Hz Spec (Supply Locally)
104 1705376 Decal - Wiring Schematic 1
105 3300396 Cover, Fuse 1
106 3310601 Nut 6-32NC 2
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
