SECTION 2 - SKYPOWER™ (BELT DRIVEN)
2-36 – JLG Accessory Manual – 3124242
18 Cont’d Stator Options (Not Shown): 1
70001969 2460050 Generator 1
70002088 2460048 Generator 1
70001974 Decal - Terminal Connections (Not Shown) 1
70000863 Fan (Not Shown) 1
70002297 Stud (Not Shown) 4
70001100 Armature, Generator (Includes Radial Ball Bearing on End
with Brushes and Fan) 1
70001384 Bearing, Ball Radial 1
18A Use 70004171 Key (was p/n 7024561) 1
18B 70001966 Bearing, Radial Ball 1
18C 70001973 Decal - Warning Moving Parts 1
18D See Note Endbell, Brush Block
(Note: Was p/n 70001385 - Use p/n 70004169 Kit as
replacement for GM Engine Machines) 1
18E 70001953 Endbell, Belt Tensioner 1
18F See Note Endbell, Shroud Assembly
(Note: Was p/n 70002290 - Use p/n 70004169 Kit as
replacement for GM Engine Machines) 1
18G 70003708 Ring, Retaining (Internal) 1
18H 70003709 Ring, Retaining (External) 1
19 2820031 Insulator 1
20 3252764 Nameplate 1
21 Locknut Options: A/R
3311405 1/4”-20NC 6
3311005 #10-24NC 2
3300454 1/4"-20NC (U-Style) 4
22 3311505 Locknut 5/16”-18NC 3
23 3311601 Nut 3/8”-16NC 2
24 3580312 Pulley, Idler 2
25 3580314 Pulley, Drive Grooved 1
26 3580348 Pulley, Belt Tensioner 1
27 3740080 Relay 2
28 3910606 Screw #6-32NC x 3/8” 8
29 3960422 Gasket 2
30 Cover, Receptacle Options: 1
30A 4060700 Cover, Side Hinged
30B 1001110873 Cover, Top HInged
31 4060802 Guard, Switch 1
32 Cover, Receptacle Options: 1
32A 4061043 Prior to S/N 0300137766
32B 1001110872 S/N 0300137766 to Present
33 4300111 Stud, Chain Assembly
(USA Built Machines Prior to S/N 0300168212 & China Built
Machines Prior to S/N B300000734) 2
34 4360336 Switch, Toggle 1
35 4460051 Connector, Strain Relief 1
36 4460071 Connector, Strain Relief 1
37 4460346 Receptacle 1
38 4460958 Receptacle, Female Twist-Lock 1
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
