SECTION 3 - SKYPOWER™ (HYDRAULICALLY DRIVEN)
3-8 – JLG Accessory Manual – 3124242
303 Generator Kit Options: 1
0272478 60Hz Spec
0272630 50Hz Spec
303A Control Box Assembly Options: 1
0861538 60Hz Control Box Assembly
0861572 50Hz Control Box Assembly
7024488 Card, Circuit - Generator Power 1
Not Available Fuse (Purchase Locally) 1
7024489 Card, Circuit - Control
Note: Same Circuit Card is used for both 60Hz &
50Hz. When replacing card, rocker switch on card
must beset for required application. 1
70000619 Harness, Circuit Card 1
303B 2460040 Generator Assembly 1 A
Use 70003631 Brushholder Assembly (Not Shown) (was p/n 7024484) 1
7024485 Breaker, Circuit 30Amp (Not Shown) 1
7024486 Boot, Breaker (Not Shown) 1
303C 4922735 Harness 1
304 1660254 Coupling 1
305 3160204 Motor, Hydraulic 1
2900788 Seal Kit - 3160204 Motor 1
306 4891800 Flatwasher 1/2" Hardened 2
4933267 ELECTRICAL DIAGRAM COMPONENTS Ref. D
401 to 402 Not Used
403 4922641 Switch Harness 1
404 4922788 Generator Harness 1 C
3990010 Diode 6 Amp 1
404A 2400060 Fuseholder (Not Shown) 1
2400064 Fuse - 5 Amp (Not Shown) 1
404B 4460374 Plug, Sealed Relay 2
4460375 Terminal 7
404C 4460880 Connector, DIN 1
404D 4460967 Plug, Male - 3 Position 1
4460465 Socket, Female 3
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
