JLG Workstation in the Sky-Boom Lifts User Manual
Page 35
SECTION 2 - SKYPOWER™ (BELT DRIVEN)
3124242
– JLG Accessory Manual –
2-7
7
Nut Options:
A/R
3311505
5/16”-18NC (Locking)
3
3311508
5/16”-18NC (Serrated Flange)
3
3311401
1/4"-20NC
2
8
Receptacle, Female Twist-Lock Options (220-240V Single):
1
4460958
60Hz
Not Available
50Hz (Supply Locally)
9
4360336
Switch, Toggle
1
4740397
Spacer, Washer (Not Shown)
1
10
4060802
Guard, Switch
1
11
Gasket Options:
2
3960422
60Hz
Not Available
50Hz (Supply Locally)
12
Cover, Receptacle Options:
1
Not Available
50Hz (Supply Locally)
12A
4060700
60Hz Cover, Side Hinged
12B
1001110873
60Hz Cover, Top Hinged
13
Cover, Receptacle Options (All Models except 18RS/24RS):
1
13A
Not Available
50Hz (Supply Locally)
13B
4061043
60Hz Cover, Side Hinged
1001110872
60Hz Cover, Top Hinged
14
Receptacle, Female Options (110-120V):
1
4460346
60Hz
Not Available
50Hz (Supply Locally)
15
Junction Box Assembly Options (See Items 101-128 for
Breakdown):
1
0861542
60Hz Spec (All Models except 18RS/24RS)
1001142914
60Hz Spec (18RS/24RS Only)
0861567
50Hz Spec
16
4761500
Lockwasher 5/16”
A/R
17
Bolt Options:
4
0641505
Bolt 5/16”-18NC x 5/8”
0641508
Bolt 5/16”-18NC x 1"
18
Box, Switch Options:
2
0860038
60Hz Spec
Not Available
50Hz Spec (Supply Locally)
19
Generator Assembly Options:
1
2460048
Caterpillar Engine (400S/460SJ/450A Series II/450AJ
Series II) (was p/n 7024493)
2460050
Caterpillar Engine (600A/600AJ/600S/600SC/600SJ/
660SCJ/660SJ/800A/800AJ/800S/860SJ)
1001119250
Caterpillar Engine (1200SJP/1250AJP/1350SJP)
Use 2460048
Deutz Engine with 60Hz Generator (400S/460SJ/600A/
600AJ/600S/600SC/600SJ/660SCJ/660SJ/800A/800AJ/
800S/860SJ) (was p/n 2460041Kit which included p/n
7024493 Replacement Generator Prior to
S/N0300075304)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
