SECTION 2 - SKYPOWER™ (BELT DRIVEN)
3124242
– JLG Accessory Manual –
2-37
39
4568735
Tube, Spacer Pulley Grooved
1
40
Flatwasher Options:
A/R
4711400
1/4" Narrow
10
4751000
#10 Wide
4
41
4711500
Flatwasher 5/16” Narrow
10
42
Not Used
43
4711800
Flatwasher 1/2” Narrow
4
44
4751600
Flatwasher 3/8” Wide
2
45
4761500
Lockwasher 5/16”
4
46
4761600
Lockwasher 3/8”
2
47
4811900
Flatwasher 8mm
1
48
4891600
Washer, Hardened 3/8”
1
49
4922925
Harness, Generator
1
50
3574163
Bracket, Relay Mounting (450A/450AJ Series II Only)
1
51
0641610
Bolt, 3/8"-16NC x 1 3/4" (450A/450AJ Series II Only)
3
52
3311605
Locknut, 3/8"-16NC (450A/450AJ Series II Only)
3
53
4711600
Flatwasher 3/8” Narrow (450A/450AJ Series II Only)
6
54
0641614
Bolt, 3/8"-16NC x 1 3/4" (Not Shown - 400/460SJ Only)
2
55
3574523
Bracket, Control Box Mounting (Not Shown - 400/460SJ Only)
2
56
1320318
Clamp (Not Shown - 400/460SJ Only)
1
57
4240018
Strap, Tie (Not Shown - 400/460SJ Only)
1
0861542
JUNCTION BOX ASSEMBLY
Ref.
D
101
0861541
Box, Junction
1
102
1060494
Cable, Electrical 12/3
2ft/.6m
103
1060708
Cable, Electrical 10/3
2.5ft/.76m
104
1705376
Decal - Wiring Schematic
1
105
3300396
Cover, Fuse
1
106
3310601
Nut 6-32NC
2
107
1060343
Cable, Electrical 10/4
1.5ft/.46m
108
Not Used
109
3910610
Bolt 6-32NC x 5/8
2
110
4360070
Circuit Breaker - 15 Amp
1
111 to 115
Not Used
116
4460425
Strain Relief, Terminal
2
117
4460426
Connector, Strain Relief
2
118 to 120
Not Used
121
4750600
Flatwasher, #6 Wide
4
122
4760600
Lockwasher #6
2
123 to 124
Not Used
125
1671092
Cover
1
126
4460963
Connector
1
127
Not Used
128
Terminal Block Assembly Options (See Items 401-410 for
Breakdown):
1
NPN
Gray Terminal Block Assembly
1001121340
Tan Terminal Block Assembly
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
