SECTION 2 - SKYPOWER™ (BELT DRIVEN)
3124242
– JLG Accessory Manual –
2-9
20 Cont’d
0641808
Deutz Engine (All except 1100SJP/1200SJP/1250AJP/
1350SJP/1500SJ)
2
0641810
Deutz Engine (1100SJP/1200SJP/1350SJP/1500SJ
Only)
3
0641812
Deutz Engine (1250AJP Prior to S/N 79823 Only)
3
0641810
Deutz Engine (1250AJP S/N 79823 to Present Only)
3
0761214
Bolt, Metric M12 x 30mm (Required Only on 18RS/24RS)
2
0771416
Bolt, Metric M14 x 40mm (Required Only on 18RS/24RS)
2
21
4071091
Shim (1250AJP Prior to S/N 79823 Only) (Not Shown)
6
22
Bracket, Box Mounting Options:
1
Use 0902888
All except 18RS/24RS (was p/n 3573668)
1001141958
Required Only on 18RS/24RS
23
Flatwasher Options:
A/R
4711800
1/2”Thin
4891800
1/2”Hardened (Required on 1100SJP/1200SJP/ 1250AJP/
1350SJP/1500SJ)
4812100
12mm (Required Only on 18RS/24RS)
4812200
14mm (Required Only on 18RS/24RS)
24
Flatwasher Options:
A/R
4711400
1/4" Thin (1/16" Thick)
4751400
1/4" Wide (1/8" Thick)
4711600
3/8"
4811702
6mm (Required Only on 18RS/24RS)
25
Bolt Options:
A/R
0641404
Bolt 1/4”-20NC x 1/2”
0641405
Bolt 1/4”-20NC x 5/8”
0641407
Bolt 1/4”-20NC x 7/8”
0641408
Bolt 1/4”-20NC x 1”
0641610
Bolt 3/8"-16NC x 1 1/4”
0760610
Bolt, Metric M6 x 20mm (Required Only on 18RS/24RS)
26
Shield Options:
A/R
Not Required
Caterpillar Engine without UGM
0
Not Required
Caterpillar Engine with UGM (400S/460S/450A Series II/
450AJ Series II/510A)
1
1001118599
Caterpillar Engine with UGM (Not Shown - Mounts on
opposite side) (600A/600AJ/600S/600SC/600SJ/660SJ/
660SJC/800A/800AJ/800S/860SJ/1100SJP/1200SJP/
1250AJP/1350SJP/1500SJ) (USA Built Machines Prior to
S/N 0300168212 & China Built Machines Prior to
S/N B300000734)
1
Not Required
Deutz Engine (18RS/24RS/400S/460S/450A Series II/
450AJ Series II/510AJ/1100SJP/1200SJP/ 1250AJP/
1350SJP/1500SJ)
0
4061049
Deutz Engine (Shown) (600A/600AJ/600S/600SC/600SJ/
660SCJ/660SJ/800A/800AJ/800S/860SJ) (USA Built
Machines Prior to S/N 0300168212 & China Built Machines
Prior to S/N B300000734)
1
27
Nut Options:
A/R
3311405
Nut 1/4"-20NC
3311605
Nut 3/8"-16NC
3300454
Nut 1/4"-20NC (U-Style) (Required Only on 450A Series II/
450AJ Series II S/N 0300160834 to Present)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
