SECTION 3 - SKYPOWER™ (HYDRAULICALLY DRIVEN)
3124242 – JLG Accessory Manual – 3-7
107 1060343 Cable, Electrical 10/4 (60Hz Spec Only) 1.5ft/.46m
108 Rail, Relay Options: 1
3640986 Prior to S/N 72911
3641533 S/N 72911 to Present
109 3910610 Bolt 6-32NC x 5/8 2
110 4360070 Circuit Breaker - 15 Amp 1
111 4460411 Marker Strip #1 2
112 4460412 Marker Strip #2 A/R
Prior to S/N 72911 2
S/N 72911 to Present 4
113 4460413 Marker Strip #3 2
114 4460414 Marker Strip #4 2
115 4460415 Marker Strip #5 A/R
Prior to S/N 72911 2
S/N 72911 to Present 4
116 4460425 Strain Relief, Terminal 2
117 4460426 Connector, Strain Relief 2
118 4460607 Terminal, End Stop 2
119 4460956 Terminal, Block End 1
120 4460957 Terminal, Block A/R
Prior to S/N 72911 5
S/N 72911 to Present 7
121 4750600 Flatwasher, #6 Wide 4
122 4760600 Lockwasher #6 2
123 4461001 Connector, Terminal (Not Shown - Located on Terminal Block)
(S/N 72911 to Present Only) 2
124 Not Used
125 1671092 Cover (60Hz Spec Only) 1
126 4460963 Connector (60Hz Spec Only) 1
127 3520189 Plug (50Hz Spec Only) 1
DECAL INSTALLATION Ref.
0272435 60Hz Spec Ref. A
0272589 50Hz Spec Ref. A
201 1705460 Decal - SkyPower™ 2
202 1705374 Decal - 240V - 60Hz (60Hz Spec Only) 1
203 Decal - 240V - 3 Phase Options 1
1705375 60Hz Spec 1
1705461 50Hz Spec 1
204 Decal, Hazardous Voltage Option 3
1705387 60Hz Spec
1705489 50Hz Spec
GENERATOR ASSEMBLY Ref.
0272207 60Hz Spec Ref. B
0272631 50Hz Spec Ref. A
301 0080239 Adapter 1
302 0100011 Locking, Compound (Not Shown) A/R
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
