JLG Workstation in the Sky-Boom Lifts User Manual
Page 129
SECTION 6 - SKYAIR™
3124242
– JLG Accessory Manual –
6-9
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
SKYAIR™ COMPRESSOR PARTS
Ref.
3600386
All Models except 400S/460SJ
Ref.
B
3600399
400S/460SJ Only
Ref.
A
1
7026632
Tank
1
2
Not Available
Bracket, Mounting
1
3
Not Available
Bracket, Mounting
1
4
Not Available
Bracket, Regulator Mounting
1
5
Not Available
Deck
1
6
Not Available
Plug
2
7
7026634
Valve, Drain
1
8
7026634
Valve, Check
1
9
7026635
Valve, Safety
1
10
7026636
Pump Assembly
1
7026659
Gasket & Seal Kit
10A
7026651
Plug, Oil Drain
10B
7026652
Gauge, Oil Sight
10C
7026653
Bearing
10D
7026654
Cap, Oil Fill
10E
7026655
Bearing
10F
7026656
Seal
11
7026637
Motor Assembly
1
Not Available
Brush Kit
1
12
Not Available
Screen, Inner
1
13
Not Available
Guard, Belt
1
14
Not Available
Support
2
15
Not Available
Bushing
1
16
4751600
Flatwasher 3/8"
18
17
4761600
Lockwasher 3/8"
10
18
0641506
Bolt 5/16"-18NC x 3/4"
4
19
0641406
Bolt 1/4"-20NC x 3/4"
8
20
Not Available
Bushing
1
21
0641610
Bolt 3/8"-16NC x 1 1/4"
10
22
0641616
Bolt 3/8"-16 x 2"
4
23
Not Available
Bolt, Flanged 1/4"-20NC x 1/2"
10
24
Not Available
Fitting
4
25
Not Available
Fitting, Barbed
1
26
3311605
Locknut 3/8"-16NC
4
27
Not Available
Fitting, Compression
1
28
Not Available
Bracket, Mounting
1
29
7026660
Filter, Oil Removal
1
30
7026661
Filter, Water Removal
1
31
70001663
Valve, Ball Shut-Off
1
32
Not Available
Bushing
1
33
Not Available
Fitting, Barbed
1
34
Not Available
Screw, Flathead 1/4"-20NC x1"
2
35
3311405
Locknut 1/4"-20NC
2
36
Not Available
Unloader
1
37
Not Available
Fitting
1
