SECTION 2 - SKYPOWER™ (BELT DRIVEN)
3124242 – JLG Accessory Manual – 2-23
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Figure 2-3. SKYPOWER™ BELT DRIVEN (PERKINS ENGINE MACHINES) Ref.
Machines without UGM: Ref.
1001097331 400S/460SJ 60Hz Spec Ref. D
1001097332 400S/460SJ 50Hz Spec Ref. C
1001097400 450A Series II/450AJ Series II 60Hz Spec Ref. D
1001097401 450A Series II 50Hz Spec Ref. D
1001097401 450AJ Series II/510AJ 50Hz Spec (ANSI Export & Japanese
Specs Only) Ref. D
1001097583 450AJ Series II/510AJ 50Hz Spec (CE & Australian Specs
Only) Ref. C
1001097512 510AJ 50Hz Spec Ref. C
Machines with UGM: Ref.
1001112101 400S/460SJ 60Hz Spec Ref. A
1001112408 400S/460SJ 50Hz Spec Ref. A
1001111404 450A Series II/450AJ Series II 60Hz Spec (Prior to
S/N 0300160835) Ref. B
1001146620 450A Series II/450AJ Series II 60Hz Spec (S/N 0300160835 to
Present) Ref. A
1001111818 450A Series II/450AJ Series II/510AJ 50Hz Spec Ref. A
1001112044 450A Series II/450AJ Series II/510AJ 50Hz (CE & Australian
Specs Only) Ref. A
1001111910 510AJ 50Hz Spec Ref. A
Note: See Model Specific Parts Manual for Boom Cable
Callouts. Ref.
1 0100011 Locking, Compound A/R
2 0100019 Locking, Compound A/R
3 Belt, Drive Options: 1
0480129 60Hz Generator
0480126 50Hz Generator
4 0641403 Bolt 1/4”-20NC x 3/8" 1
5 Bolt 1/4”-20NC Options: 4
0641404 1/2" Length
0641407 7/8” Length
0641408 1" Length
6 Bolt 5/16”-18NC Options: 4
0641505 5/8" Length
0641508 1" Length
7 0641516 Bolt 5/16"-18NC x 2" 3
8 0641614 Bolt 3/8"-16NC x 1 3/4" (Not Required on 510AJ) 2
9 0641808 Bolt 1/2”-13NC x 1" 4
10 0701217 Bolt M12 x 45mm 3
11 0902888 Bracket, Junction Box Mounting 1
12 Junction Box Assembly Options (See Items 101-128 for
Breakdown): 1
0861542 60Hz Spec
0861567 50Hz Spec
13 Control Box Assembly Options: 1
0861538 60Hz Generator
0861572 50Hz Generator
