SECTION 2 - SKYPOWER™ (BELT DRIVEN)
3124242 – JLG Accessory Manual – 2-33
ELECTRICAL DIAGRAM COMPONENTS Ref.
4933283 400S/460SJ/ 600A/600AJ/600S/600SJ/660SJ/800A/800AJ/800S/
860SJ Ref. 2/B
4933316 450A/450AJ Series II Ref. 1/A
301 Generator Harness Options: 1
4922905 Harness for 400S/460SJ/ 600A/600AJ/600S/600SJ/660SJ/
800A/800AJ/800S/860SJ 1/A
4923199 Harness for 450A/450AJ Series II 1/A
301A 4460374 Plug, Sealed Relay 1
4460375 Terminal 4
301B 4460967 Plug, Male - 3 Position 1
4460465 Socket, Female 3
301C 2400060 Fuseholder (Not Shown) 2
2400064 Fuse - 5 Amp (Not Shown) 2
302 to 303 Not Used
304 4922641 Switch Harness 1
305 See Note Cable, Electrical
(Note: See Model Specific Parts Manual for Call-out.) A/R
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
