JLG 600A_AJ Parts Manual - Manual (Page 90)

2-54 3120841
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
12 3910608 Screw #6-32NC x 1/2in 6
13 3640970 Rail 1
14 4460602 Barrier, Terminal 1
15 4460601 Block, Terminal 10
16 4460603 Bussbar - 10 Position (Requires being cut into (2) 5 position
bussbars) 1
17 4460631 Marker, Terminal (Negative) A/R
18 4460600 Block, Terminal A/R
19 4460628 Marker, Terminal (1-50) A/R
20 4460607 Stop, Terminal 1
21 4750600 Flatwasher #6 Regular 12
22 3740112 Relay, Bosch 1
23 4360314 Switch, Toggle A/R
24 Switch, Contact Block Options: 1
4360282 Prior to S/N 0300044652
4360476 S/N 0300044652 to S/N 0300064249
25 2760105 Housing, Display Light 1
2920129 Bulb, Light 7
4120035 Socket, Light 7
26 4420038 Insulation, Adhesive Foam 4in/10cm
27 1702610 Decal - Ground Control Display 1
28 4460526 Connector, Strain Relief 1
29 4460428 Connector, Strain Relief 3
30 4460426 Connector, Strain Relief 1
31 4740444 Washer, Special A/R
32 4060906 Shield, Toggle Switch A/R
33 2420172 Gauge, Hourmeter 1
34 0721005 Screw #10-24NC x 5/8in A/R
35 3311001 Nut #10-24NC (Prior to S/N 0300055241) A/R
36 4751000 Flatwasher #10 Regular A/R
37 Screw Options: A/R
0721004 Screw #10-24NC (Prior to S/N 0300055241)
3900268 Screw #10-24NC x 1/2in (S/N 0300055241 to
S/N 0300064249)
38 3300205 Nut, Retainer 4
39 0641506 Bolt 5/16in-18NC x 3/4in 4
40 0100011 Compound, Locking A/R
41 3539219 Plate, Reinforcement 1
42 3740049 Relay - SPDT A/R
43 4460630 Marker, Terminal (Ignition) A/R
44 4760600 Lockwasher #6 6
45 3310601 Nut #6-32NC 6
46 3700010 Reflector (Prior to S/N 0300027331 Only) 1
47-51 Not Used
52 3300390 Nut with Weather Resistant Boot (S/N 0300027331 to
S/N 0300044652) 1
53 3520054 Plug, Hole (S/N 0300028933 to S/N 0300035129) 1
54 1670829 Bezel (S/N 0300035129 to S/N 0300069000) 1
FIGURE 2-15. GROUND CONTROL BOX INSTALLATIONS (PRIOR TO S/N 0300064249)
(CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
