440 4922666 Cable, Analyzer 1 1/A
440A 4460226 Socket, Female 4
440B 4460761 Connector, Female 4- Position 1
4460227 Pin, Male 4
441 4933214 Ground Control Box Wiring Diagram (Not Shown -
See Items 301 to 310 for Breakdown) 1
4922515 ENGINE HARNESS ASSEMBLY Ref. 5/E
501 4922515 Harness, Assembly 1
502 to 518 Not Used
519 4460424 Plug, Male - 2 Position 1
520 4460268 Socket, Female 2
521 4460880 DIN Connector without Diode A/R
522 to 535 Not Used
536 4460890 Housing - 2 Position 1
537 4460889 Terminal 2
538 4460460 Connector, Male - 4 Position 1
539 4460457 Terminal, Female A/R
540 4460458 Seal, Terminal A/R
541 to 556 Not Used
557 4460871 Socket, Female A/R
558 to 566 Not Used
4922508 VALVE HARNESS ASSEMBLY Ref. 4/D
601 4922508 Harness, Assembly 1
602 to 616 Not Used
617 4460880 DIN Connector 15
618 4460320 Connector, Female - 2 Position 1
619 4460267 Pin, Male 5
620 4460424 Connector, Male - 2 Position 1
621 4460268 Pin, Female 5
622 4460871 Socket, Female 28
623 to 624 Not Used
625 4460326 Connector, Male - 3 Position 1
626 4460445 Connector, Female - 3 Position 1
627 to 628 Not Used
STANDARD HARNESS COMPONENTS Ref.
701 to 702 Not Used
703 See Note Pump Harness (Note: Not Available for Purchase) 1
703A 7007497 Plug (Pump End) 1
703B 7007498 Plug (Engine Harness End) 1
704 See Note Controller Harness Assembly (Lift and Swing)
(Note: Not Available for Purchase) 1
704A 7022819 Plug, Male - 8 Position (Natural) 1
FIGURE 7-9. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (S/N 0300064270 TO
S/N 0300069000) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
