3120841 5-13
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-4. LEVEL (UPRIGHT) CYLINDER ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
LEVEL (UPRIGHT) CYLINDER ASSEMBLY Ref
1683299 Original Equipment Ref F
1684498 Service Replacement Ref C
Note: Original Equipment components may have
been replaced with Service Replacement
components part. Identify p/n stamped on
cylinder before ordering parts. Ref
1 Barrel Weldment Options: 1
1683300 Prior to S/N 0300056430
Use 0370035 S/N 0300056430 to S/N 0300069000 (Original
Equipment) (was p/n 1684014)
0370035 Service Replacement
1A 0961949 Bushing, Composite 2
2 Rod Weldment Options: 1
1683302 Prior to S/N 0300056430
1684015 S/N 0300056430 to S/N 0300069000
2A 0961949 Bushing, Composite 2
3 1683067 Head 1
4 3480206 Piston 1
5 0961898 Bushing, Tapered (Use item #24 in place of sup-
plied bolts) 1
6 4566501 Spacer, Tube 1
7 4640509 Cartridge, Valve 1
2900792 Seal Kit - 4640509 Valve 1
8 4640605 Cartridge, Valve 1
2900792 Seal Kit - 4640605 Valve 1
9 3932032 Bolt, Socket Head 5/16in-11NC x 2in 8
10 2220883 Plug, O-Ring 2
11 Use 2901285 Ring, Lock 2
12 Use 2901285 Seal, Hydrolock 2
13 Use 2901285 O-Ring 1
14 Use 2901285 Ring, Back-up 2
15 Use 2901285 Ring, Wear 1
16 Use 2901285 O-Ring 1
17 Use 2901285 Ring, Back-up 1
18 Use 2901285 Seal, Rod 1
19 Use 2901285 Wiper 1
20 0100011 Compound, Locking A/R
21 0100038 Primer, Locking A/R
22 3760372 Washer, Ring 1
23 Not Used
24 0630536 Bolt 3/8in-16NC x 1-1/2in 3
25 2220886 Plug, O-Ring 1
26 0100063 Adhesive A/R
27 to 50 Not Used
51 2901285 Seal Kit (Includes Items 11-19) 1
