3120841 1-3
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
.
FIGURE 1-1. 2WD FRONT AXLE AND STEERING INSTALLATIONS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
AXLE INSTALLATIONS - OSCILLATING Ref.
0255404 8FT/2.4m Wide Machines (Prior to S/N 0300041868) Ref. 7
0256398 8FT/2.4m Wide Machines (S/N 0300041868 to
S/N 0300069000) Ref. 3
0255418 7FT/2.1m Wide Machines (Prior to S/N 0300041868) Ref. 6
0256397 7FT/2.1m Wide Machines (S/N 0300041868 to
S/N 0300069000) Ref. 4
1 Axle Weldment Options: 1
4844929 8 ft/2.4m Wide Machine
4844960 7 ft/2.1m Wide Machine
2 1683280 Lockout Cylinder Assembly (See Section 5 for
Breakdown) 2
3 Pin, Pivot Options: 1
Use 3422592 Prior to S/N 0300041868 (was p/n 3422431)
3422592 S/N 0300041868 to S/N 0300069000
4 3422426 Pin, Cylinder 4
5 3841143 Keeper, Pin 4
6 0641608 Bolt 3/8in-16NC x 1in 4
7 0100011 Compound, Locking A/R
8 3841258 Keeper, Pin 1
9 0642012 Bolt 5/8in-11NC x 1-1/2in 1
10 4740158 Thrustwasher 1
11 4640871 Valve, Cam 1
7012693 Seal Kit - 4640871 Valve 1
7002840 Tool, Pin Removal 1
12 0641414 Bolt 1/4in-20NC x 1-7/8in 4
13 4711400 Flatwasher 1/4in Thin 8
14 Not Used
15 3538047 Plate, Wear 2
16 4070878 Shim, (.06) 4
17 4070879 Shim, (.12) 4
18 0641612 Bolt 3/8in-16NC x 1-1/2in 4
19 4711600 Flatwasher 3/8in Thin 4
20 1100098 Cam, Lockout 1
21 0641820 Bolt 1/2in-13NC x 2in 3
22 4751800 Flatwasher 1/2in Regular 9
23 4566832 Tube, Spacer 3
24 Not Used
25 0961950 Bushing 2
