5-10 3120841
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
12 0100038 Primer, Locking A/R
13 See Note Seal (Note: Use Item 51) 2
14 See Note Ring, Lock (Note: Use Item 51) 2
15 See Note O-Ring (Note: Use Item 51) 1
16 See Note Ring, Back-up (Note: Use Item 51) 1
17 See Note Ring, Wear (Note: Use Item 51) 1
18 See Note O-Ring (Note: Use Item 51) 1
19 See Note Ring, Back-up (Note: Use Item 51) 1
20 See Note Seal, Rod (Note: Use Item 51) 1
21 See Note Wiper (Note: Use Item 51) 1
22 Not Used
23 4640932 Cartridge, Valve 1
7011112 Seal Kit - 4640932 Valve 1
24 2220883 Plug, O-Ring 8
25 Bolt Options: 3
0630534 600A - Bolt #10 - 24NC x 1in
0630535 600AJ - Bolt 1/4in - 20NC x 1-1/8in
26 Not Used
27 0100063 Adhesive A/R
28 to 50 Not Used
51 Seal Kit Options (Includes Items 13-21): 1
2901303 600A
2901301 600AJ
FIGURE 5-3. PLATFORM LEVEL CYLINDER ASSEMBLIES (S/N 0300024714 TO S/N 0300069000)
(CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
