SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
.
FIGURE 3-8. BOOM WIPERS INSTALLATIONS (OPTIONAL)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
BOOM WIPER INSTALLATION (STANDARD PARTS) Ref.
0256276 BOOM WIPERS INSTALLATION - 600A Ref. 2
0256366 BOOM WIPERS INSTALLATION - 600AJ Ref. 3
1 3200386 Mount, Wiper (Tower Top) 2
2 0540078 Brush, Wiper (Tower Top and Bottom) 2
3 2660071 Holder, Brush (Tower Top and Bottom) 2
4 3820001 Rivet 30
5 0641409 Bolt 1/4in-20NC x 1-1/8in 8
6 4761400 Lockwasher 1/4in 8
7 3311401 Nut 1/4in-20NC 8
8 3200388 Mount, Wiper (Tower Bottom) (Prior to S/N 0300038141) 1
9 0641611 Bolt 3/8in-16NC x 1-3/8in (Prior to S/N 0300038141) 2
10 3200387 Mount, Wiper (Tower Side - Left Side) (Prior to
S/N 0300038141) 1
3200407 Mount, Wiper (Tower Side - Left Side) (S/N 0300038141
to S/N 0300069000)
11 3200393 Mount, Wiper (Tower Side - Right Side) (Prior to
S/N 0300038141) 1
3200408 Mount, Wiper (Tower Side - Right Side) (S/N 0300038141
to S/N 0300069000)
12 0540099 Brush, Wiper (Tower Side) 2
13 2660099 Holder, Brush (Tower Side) 2
14 0100011 Compound, Locking A/R
15 0641607 Bolt 3/8in-16NC x 7/8in 4
16 3200389 Mount, Wiper (Main Top) 1
17 0540083 Brush, Wiper (Main Top and Bottom) 2
18 2660082 Holder, Brush (Main Top and Bottom) 2
19 3200390 Mount, Wiper (Main Bottom) 1
20 0641608 Bolt 3/8in-16NC x 1in 2
21 0641611 Bolt 3/8in-16NC x 1-3/8in 2
22 Mount, Wiper (Main Side - Left Side) Options: 1
3200394 600A
3200396 600AJ
23 Mount, Wiper (Main Side - Right Side) Options: 1
3200395 600A
3200397 600AJ
24 Brush, Wiper (Main Side) 2
0540104 600A
0540104 600AJ (Prior to S/N 0300049396)
0540107 600AJ (S/N 0300049396 to S/N 0300069000)
25 Holder, Brush (Main Side) 2
2660105 600A
2660105 600AJ (Prior to S/N 0300049396)
2660109 600AJ (S/N 0300049396 to S/N 0300069000)
