2-24 3120841
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
37 0641610 Bolt 3/8in-16NC x 1-1/4in 21
38 3311605 Locknut 3/8in-16NC 22
39 4751600 Flatwasher 3/8in Regular 44
40 0701414 Bolt M14 x 30mm 4
41 4891600 Flatwasher 3/8in Hardened 2
42 0641406 Bolt 1/4in-20NC x 3/4in 12
43 4751400 Flatwasher 1/4in Regular 20
44 3311405 Locknut 1/4in-20NC 13
45 0721004 Bolt #10-24NC x 5/8in 2
46 3311005 Locknut #10-24NC 2
47 4751000 Flatwasher #10 Regular 2
48 1320022 Clamp, Hose 6
49 2220273 Fitting, Reducer 2
50 2180536 Fitting, Straight 1
51 2220313 Fitting,90° 1
52 2750532 Hose 3/8in 6ft./1.83m
53 2220250 Fitting, Reducer 1
54 2220459 Fitting, 90° 1
55 2720271 Hose 3/16in 15ft./4.6m
56 0641812 Bolt 1/2in-13NC x 1-1/2in 4
57 0100020 Sealant, Thread A/R
58 0100011 Compound, Locking A/R
59 Not Used
60 2720351 Coupling, Rubber Intake 6in./15cm
61 0700810 Bolt M8 x 20mm 4
62 Use 2910000 Actuator Assembly (was p/n 0060033) (See Section 7 for
Breakdown) 1
63 to 64 Not Used
65 3290801 Nut M8 3
66 0080177 Air Intake Adapter Weldment 1
67 0641510 Bolt 5/16in-18NC x 1-1/4in 3
68 3311505 Locknut 5/16in-18NC 3
69 0961986 Bushing, Flanged 2
70 2901358 Battery Cable Kit 1
70A 7016800 Cable, Battery (Red) 1
70B 7016812 Cable, Battery (Black) 1
70C 7016802 Cable (Red) 1
70D 7016803 Cable (Red) 1
70E 7016804 Cable (Red) 1
70F 7016805 Cable (Black) (Prior to S/N 0300025556) 1
71 4460611 Terminal, Battery Jumper Post 1
72 4360294 Breaker, Circuit - 30 Amp 1
73 1320222 J-Clip 3/8in 1
74 1320223 J-Clip 1/2in 3
75 0641606 Bolt 3/8in-16NC x 3/4in 3
76 3422533 Pin, Hitch 1
77 3790152 O-Ring 1
78 3960407 Gasket 1
FIGURE 2-8. DEUTZ ENGINE INSTALLATION - WITHOUT NOISE REDUCTION (PRIOR TO S/N
0300029930) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
