SECTION 1 FRAME
.
FIGURE 1-2. 4WD FRONT AXLE AND STEERING INSTALLATIONS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
AXLE INSTALLATIONS - OSCILLATING Ref.
0255415 Prior to S/N 0300041868 Ref. 4
0256392 S/N 0300041868 to S/N 0300069000 Ref. 3
1 4845041 Axle Weldment 1
2 1683280 Lockout Cylinder Assembly (See Section 5 for
Breakdown) 2
3 Pin, Pivot Options: 1
Use 3422592 Prior to S/N 0300041868 (was p/n 3422431)
3422592 S/N 0300041868 to S/N 0300069000
4 3422426 Pin, Cylinder 4
5 3841143 Keeper, Pin 4
6 0641608 Bolt 3/8in-16NC x 1in 4
7 0100011 Compound, Locking A/R
8 3841258 Keeper 1
9 0642012 Bolt 5/8in-11NC x 1-1/2in 1
10 4740158 Thrustwasher 1
11 4640871 Valve, Cam 1
7012693 Seal Kit - 4640871 Valve 1
7002840 Tool, Pin Removal 1
12 0641414 Bolt 1/4in-20NC x 1 3/4in 4
13 4711400 Flatwasher 1/4in Thin 4
14 Not Used
15 3538047 Plate, Axle Wear 2
16 4070878 Shim (.06) A/R
17 4070879 Shim (.12) A/R
18 0641608 Bolt 3/8in-16NC x 1in 4
19 4711600 Flatwasher 3/8in Thin 4
20 1100098 Cam, Lockout 1
21 0641816 Bolt 1/2in-13NC x 2in 3
22 4751800 Flatwasher 1/2in Regular A/R
23 4566832 Spacer, Tube 3
24 0961950 Bushing, Bronze 2
AXLE INSTALLATIONS - FIXED Ref.
0255417 Prior to S/N 0300041868 Ref. 3
0256625 S/N 0300041868 to S/N 0300069000 Ref. 3
101 4845041 Axle Weldment 1
102 3539877 Plate, Stop 2
103 Pin, Pivot Options: 1
Use 3422592 Prior to S/N 0300041868 (was p/n 3422431)
3422592 S/N 0300041868 to S/N 0300069000
104 4070944 Shim (.06) A/R
105 4070945 Shim (.25) A/R
106 0641820 Bolt 1/2in-13NC x 2-1/2in 2
107 0100019 Compound, Locking A/R
108 3841258 Keeper, Pin 1
