4933214
GROUND CONTROL BOX DIAGRAMS
Ref.
2/B
301
2920129
Bulb, Light
6
302 to 306
Not Used
307
2400065
Fuse, 30Amp
1
308
2400066
Fuse, Holder W/Cover
1
309
Not Used
310
4460708
Receptacle, Female - 15 Position
2
4460226
Socket, Female
10
4922637
Harness, Jumper (Not Shown)
1
GROUND CONTROL HARNESS ASSEMBLY
Ref.
401 to 416
Not Used
417
3740049
Relay
2
418 to 425
Not Used
426
4460426
Connector, Strain Relief
2
427
4460470
Nut, Terminal
1
428
4460471
Lockwasher, Terminal
1
429
Not Used
430
4460526
Connector, Strain Relief
1
431
4460874
Connector (Natural)
1
432
4460875
Connector (Gray)
1
433
4460905
Connector, Amp Seal Plug
4
434 to 436
Not Used
437
4922515
Engine Harness Assembly (Not Shown - See 501 to
566 for Breakdown)
1
438
4922508
Valve Harness Assembly (See 601 to 628 for Break-
down)
1
439
4922638
Ground Control Box Harness Assembly
1
3/C
439A
4460418
Connector, Female- 6 Position
9
4460419
Socket, Female
27
439B
4460876
Connector, 35- Position
1
4460871
Socket, Female
A/R
4460905
Seal, Plug
2
439C
4460866
Receptacle, Female- 19 Pin
1
4460464
Pin, Male Deutsch (16 Gauge)
10
439D
4460878
Housing, Terminal- 4 Position
1
4460887
Terminal (12 Gauge)
3
439E
4120035
Base, Light
6
4460634
Terminal (16 Gauge)
7
439F
4460873
Connector, 35- Position (Black)
1
4460871
Socket, Female
A/R
4460635
Terminal (12 Gauge)
5
439G
4460871
Socket, Female
A/R
439H
4460434
Plug, Male 15- Position
2
4460227
Pin
A/R
439I
3990010
Diode - 6 Amp (Not Shown)
2
FIGURE 7-9. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (S/N 0300064270 TO
S/N 0300069000) (CONTINUED)
