JLG 600A_AJ Parts Manual User Manual
Page 21
3120841
1-13
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
.
FIGURE 1-4. TIRE AND WHEEL DRIVE INSTALLATIONS
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
WHEEL DRIVE INSTALLATIONS
Ref.
0255413
2WD (Prior to S/N 0300056718)
Ref.
5/C
0270123
2WD (S/N 0300056718 to S/N 0300069000)
Ref.
1/A
0255414
4WD (Prior to S/N 0300056718)
Ref.
6/C
0270124
4WD (S/N 0300056718 to S/N 0300069000)
Ref.
3/D
1
2780213
Drive Hub Assembly (1 Per Drive Wheel) (See Figure 1-5
for Breakdown)
A/R
2
Drive Brake Assembly (1 Per Drive Wheel) (See Figure1-6
for Breakdown)
A/R
0920084
Prior to S/N 0300033476
0920110
S/N 0300033476 to S/N 0300056718
Use 0920119
S/N 0300056718 to S/N 0300069000 (was p/n 0920117)
3
Drive Motor Assembly (1 Per Wheel Drive) Options:
A/R
3160205
2WD (See Figure 1-7 for Breakdown)
2
3160204
4WD (See Figure 1-8 for Breakdown)
4
4
3300106
Lugnut (8 Per Wheel)
A/R
5
0682016
Bolt 5/8in-11NC x 2in (8 Per Drive Wheel) (Grade 8)
A/R
6
4892000
Flatwasher 5/8in Hardened(8 Per Drive Wheel)
A/R
7
0100011
Compound, Locking (Prior to S/N 0300068274)
A/R
8
Stud (2 Per Drive Wheel) Options:
A/R
4300120
Stud 1/2in-13NC x 5-1/2in (Prior to S/N 0300056718)
4300097
Stud 1/2in-13NC x 5-1/8in (S/N 0300056718 to
S/N 0300069000)
9
4891800
Flatwasher 1/2in Hardened (2 Per Drive Wheel)
A/R
10
3311801
Nut 1/2in-13NC (2 Per Wheel Drive)
A/R
8 FT/2.4M WIDTH MACHINES TIRE AND WHEEL
INSTALLATION OPTIONS:
Ref.
0255420
TIRE AND WHEEL INSTALLATION - PNEUMATIC
Ref.
-
0271612
TIRE AND WHEEL INSTALLATION - PNEUMATIC
Ref.
1
0255421
TIRE AND WHEEL INSTALLATION - FOAM FILLED
Ref.
-
0271613
TIRE AND WHEEL INSTALLATION - FOAM FILLED
Ref.
1
Note: Assemblies may require ballast/foam filling to
manufacturer’s specifications prior to installing on a
machine. Refer to Operation & Safety or Service &
Maintenance Manuals. Purchase individual tire and/or
rim only if able to foam fill tire & wheel assembly, other-
wise, purchase complete assembly.
Ref.
0255513
Tire and Wheel Assembly - Galaxy Pneumatic (Right Side)
2
1/A
0271609
Tire and Wheel Assembly - OTR Pneumatic (Right Side)
2
A
0255605
Tire and Wheel Assembly - Galaxy Foam-Filled (Right
Side)
2
-/-
0271611
Tire and Wheel Assembly - OTR Foam-Filled (Right Side)
2
A
0255514
Tire and Wheel Assembly - Galaxy Pneumatic (Left Side)
2
A
0271608
Tire and Wheel Assembly - OTR Pneumatic (Left Side)
2
1/A
0255606
Tire and Wheel Assembly - Galaxy Foam-Filled (Left Side)
2
-/-
0271610
Tire and Wheel Assembly - OTR Foam-Filled (Left Side)
2
A
