3120841 4-17
SECTION 4 PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
FIGURE 4-4. PLATFORM CONSOLE ASSEMBLY (WITH ADE SYSTEM) (S/N 0300064249 TO S/N
0300069000)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
CONSOLE BOX & FOOTSWITCH ASSEMBLIES Ref.
0861415 S/N 0300064249 to S/N 0300064270 Ref. E
0861474 S/N 0300064270 to S/N 0300068290 Ref. B
0861517 S/N 0300068290 to S/N 0300069000 Ref. A
1 0100009 Sealant A/R
2 0100020 Sealant A/R
3 0100035 Compound, Locking A/R
4 0100048 Grease, Dielectric A/R
5 0140011 Alarm 1
6 0630464 Screw, Button Head #10-24NC x 1/2in 2
7 0641404 Bolt 1/4in-20NC x 1/2in 8
8 0641406 Bolt 1/4in-20NC x 3/4in 4
9 0641408 Bolt 1/4in-20NC x 1in 3
10 0641416 Bolt 1/4in-20NC x 2in 4
11 0641610 Bolt 3/8in-16NC x 1-1/4in 4
12 Box, Console Options: 1
Note: No exact S/N break exists.
S/N 0300067725 to S/N 0300068965 may use
either box. Ref.
0861414 Box, Console - Aluminum (See Items 101-107 for
Breakdown)
0861537 Box, Console - Die Cast (See Items 110-115 for
Breakdown)
13 0902751 Bracket, Card Support 4
14 Cable Options: A/R
1060330 Cable, 16/3 (S/N 0300064249 to S/N 0300064270) 7ft/2.1m
1060918 Cable, 18/3 (S/N 0300064270 to S/N 0300069000) 8ft/2.4m
15 Use 1001129555 Controller Assembly (Lift & Swing) (See Figure 4-7 for
Breakdown) (was p/n 1600317 & 1001118417)
16 Use 1001118416 Controller Assembly (Drive & Steer) (See Figure 4-10
for Breakdown) (was p/n 1600318) 1
17 1600313 Controller, Module (Re-calibration Required when
Replaced) 1
18 1670829 Bezel 1
19 1702564 Decal (Stop) 1
20 1702565 Decal (Drive and Steer) 1
21 1702566 Decal (Lift and Swing) 1
22 1702567 Decal (Function Speed) 1
23 1702676 Decal (Horn) 1
24 1704260 Decal - EMS 1
25 2560136 Handle, Knob 1
26 2760105 Housing, Display Light 1
27 2920129 Bulb, Light 12
28 3300408 Locknut, Nylon Insert 2
29 3311405 Locknut 1/4in-20NC 11
30 3311605 Locknut 3/8in-16NC 4
31 3520028 Plug, Hole 1/2in 4
