JLG 600A_AJ Parts Manual User Manual
Page 219
3120841
5-31
SECTION 5
CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
.
FIGURE 5-12. CYLINDER BELLOWS INSTALLATION (OPTIONAL)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0255927
CYLINDER BELLOWS INSTALLATION (600A)
Ref.
1
1
0460152
Bellows, Cylinder (Master and Platform Level Cylinders)
2
2
0460155
Bellows, Cylinder (Main Lift Cylinder)
1
3
0460154
Bellows, Cylinder (Tower Lift Cylinder)
1
0255928
CYLINDER BELLOWS INSTALLATION (600AJ)
Ref.
1
101
0460151
Bellows, Cylinder (Master and Platform Level Cylinders)
1
102
0460155
Bellows, Cylinder (Main Lift Cylinder)
1
103
0460161
Bellows, Cylinder (Articulating Jib Lift Cylinder)
1
104
0460160
Bellows, Cylinder (Articulating Jib Level Cylinder)
1
105
0460154
Bellows, Cylinder (Tower Lift Cylinder)
1
1282490
CYLINDER BELLOWS INSTALLATION (FRAME)
Ref.
-
0255482
2WD/2WS and 4WD/2WS 8FT/2.4m Width Machines
Ref.
-
with Oscillating Axle
0255483
2WD/2WS and 4WD/2WS 8FT/2.4m Width Machines
Ref.
-
with Fixed Axle
0255486
2WD/4WS and 4WD/2WS 8FT/2.4m Width Machines
Ref.
-
with Oscillating Axle
0255487
2WD/4WS and 4WD/4WS 8FT/2.4m Width Machines
Ref.
-
with Fixed Axle
0255484
2WD/2WS 7FT/2.1m Width Machines with Oscillating
Ref.
-
Axle
0255485
2WD/2WS 7FT/2.1m Width Machines with Fixed Axle
Ref.
-
0255488
2WD/4WS 7FT/2.1m Width Machines with Oscillating
Ref.
-
Axle
0255489
2WD/4WS 7FT/2.1m Width Machines with Fixed Axle
Ref.
-
201
Bellows, Cylinder (Steer Cylinder)
A/R
0460150
8FT/2.4m Width Machines
0460157
7FT/2.1m Width Machines
202
Bellows, Cylinder (Oscillating Axle Cylinders)
A/R
0460159
With Oscillating Axle
Not Required
Without Oscillating Axle
