JLG 600A_AJ Parts Manual User Manual
Page 275
3120841
7-41
SECTION 7
ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
705
See Note
Controller Harness/Circuit Board Assembly (Drive
and Steer) (Note: Not Available for Purchase)
1
705A
7022825
Plug, Female - 8 Position (Black)
1
705B
4460871
Socket, Female
7
706 to 707
Not Required
OPTIONAL HARNESS COMPONENTS
Ref.
801
4921928
4WS Valve Harness
1
801A
4460268
Socket, Female
3
801B
4460445
Connector, Female - 3 Position
1
801C
4460499
Connector, DIN with Diode
2
802
4921927
Jib Valve Harness (600AJ Only)
1
802A
4460326
Plug, Male - 3 Position
1
802B
4460267
Pin, Male
3
802C
4460499
Connector, DIN with Diode
2
803
0257887
Alarm Harness (Includes Alarm)
1
803A
4460424
Plug, Male - 2 Position
1
803B
4460268
Socket, Female
2
804
0255917
Strobe Light Harness (Includes Strobe Light)
1
804A
4460320
Connector, Female - 2 Position
1
804B
4460267
Pin, Male
2
805
0256202
AC to Platform Receptacle Components
Ref.
4/G
805A
0860038
Box, Switch
1
805B
Not Required
Receptacle
1
805C
Not Required
Shield, Cover
1
805D
Not Required
Connector, Strain Relief
1
805E
4460709
Plug, Male
2
805F
4921820
Harness-Receptacle Box to Boom
1
1060494
Cable, Electrical - 12/3
2.5ft/0.8m
805G
4460710
Connector, Female
2
806
Generator Electrical Components
4933158
110V
Ref.
1/A
4933162
220V
Ref.
1/A
3990010
Diode - 6 Amp (Not Shown)
1
806A
4922483
Harness - On/Off Switch
1
806B
4460320
Connector, Female - 2 Position
1
806C
4460267
Pin, Male
2
806D
4460424
Plug, Male - 2 Position
1
806E
4460268
Socket, Female
2
806F
4922482
Powermite Control Box to Relay
1
806G
4460027
Receptacle, Electrical (Industrial) (110V)
1
4460125
Receptacle, Electrical (220V)
1
806H
4460190
Receptacle, Electrical (Standard) (110V)
1
4460125
Receptacle, Electrical (220V)
1
FIGURE 7-8. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (S/N 0300064249 TO
S/N 0300064270) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
