JLG 600A_AJ Parts Manual User Manual
Page 231
3120841
6-11
SECTION 6
HYDRAULIC
S
E
C
T
I
O
N
6
H
Y
D
R
A
U
L
I
C
FIGURE 6-4. HYDRAULIC DIAGRAM - STANDARD
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
2792188
HYDRAULIC DIAGRAM - STANDARD (600A)
Ref.
18
2792189
HYDRAULIC DIAGRAM - STANDARD (600AJ)
Ref.
19
1 to 2
Not Used
3
2220377
Fitting, Straight
3
4
2220646
Fitting, 90°
2
5
2752655
Hose
1
6
2220578
Fitting, 90°
3
7
2220366
Fitting, 90°
2
8
2220385
Fitting, Tee
2
9
2220618
Fitting, Reducer
3
10
2752500
Hose
1
11
2752519
Hose
1
12
2753132
Hose
1
13
2220472
Fitting, 90°
2
14
2752928
Hose
1
15
2220375
Fitting, Straight
2
16
2752591
Hose
1
17
2220466
Fitting, 90°
8
18
2220415
Fitting, Straight
5
19
Not Used
20
2752723
Hose
1
21
2220379
Fitting, Straight
2
22
2752656
Hose
1
23
2220567
Fitting, 90°
1
24
2752724
Hose
1
25
2220376
Fitting, Straight
1
26
2220810
Fitting, Reducer
1
27
4640744
Valve, Check
1
28
2752604
Hose (Note: Also Requires #69 & #68 for Complete
Run Up Boom)
2
29
2752929
Hose
1
30
2220602
Fitting, Tee
2
31
2220619
Fitting, Reducer
6
32
2220416
Fitting, 90°
1
33
2752635
Hose
1
34
2753133
Hose
1
35
2220497
Fitting, Straight
2
36
2752573
Hose
5
37
2220414
Fitting, Straight (600A - Qty.1 /600AJ - Qty.2)
(Prior to S/N 0300058640)
A/R
38
2220428
Fitting, Quick Coupling (600A - Qty.3 /600AJ - Qty.4)
A/R
39
2220429
Cap, Dust (600A - Qty.3 /600AJ - Qty.4)
A/R
40
2220873
Fitting
2
41
2752600
Hose
2
42
2220582
Fitting, Straight
6
43
2752506
Hose (600A)
1
2752516
Hose (600AJ)
1
