SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
.
FIGURE 2-1. CONTROL VALVES INSTALLATIONS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
CONTROL VALVES INSTALLATIONS Ref.
0255440 600A 2WS Ref. 9
0255442 600A 4WS Ref. 9
0255441 600AJ 2WS Ref. 11
0255443 600AJ 4WS Ref. 9
1 Main Valve Block Assembly (See Figure 2-2 for Breakdown)
Options: 1
4640920 Prior to S/N 0300041204
4641097 S/N 0300041204 to S/N 0300069000
2 3600243 Auxiliary Pump Assembly 1 A
2A 7013755 Replacement Motor 1
7013799 Brush Kit - 7013755 Motor 1
2B 7013711 Coupling 1
2C 7013796 Replacement Pump 1
See Note Seal Kit (Note: Not Available - Purchase Individual
Components) 1
7016700 Seal, Oil 1
7016701 O-Ring 1
7016702 O-Ring 1
2D 7022203 Bolt (Pump to Bracket) 4
2E 7016744 Bolt (Motor to Bracket) 2
3 4640930 Manual Descent Valve Assembly 1
3A 7012954 Cartridge, Needle 4
7012953 Seal, Kit - 7012954 Cartridge 4
3B 7012961 Knob 4
3C 7012694 Cartridge, Pump 1
7012699 Seal Kit - 7012694 Cartridge 1
4 4640908 Counterbalance Valve Assembly 1
4A 7011328 Cartridge, Counterbalance 2
2900770 Seal Kit - 7011328 Cartridge 2
5 Not Used
6 4640866 Manual Pull Valve Assembly 1
2900708 Seal Kit - 4640866 Valve 1
6A 7012959 Knob 1
7 Not Used
8 Not Used
9 4640907 Brake Valve Assembly 1
9A 7012941 Cartridge Without Coil 1
7012907 Seal Kit - 7012941 Cartridge 1
9B 7012944 Coil 1
10 2120146 Hydraulic Pressure Filter Assembly 1
10A 2120150 Element, Filter 1
10B 7016312 Switch, Clog Indicator 1
