3120841 5-27
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
.
FIGURE 5-10. TELESCOPE (MAIN BOOM) CYLINDER ASSEMBLIES
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1683307 TELESCOPE CYLINDER ASSEMBLY - 600A Ref. 3/E
1683317 TELESCOPE CYLINDER ASSEMBLY - 600AJ Ref. 3/E
1 Barrel Options: 1
1683308 600A
1683318 600AJ
2 Rod Options: 1
1683310 600A
1683320 600AJ
3 3480212 Piston 1
4 1683054 Head 1
5 4566425 Spacer 1
6 0961896 Bushing, Tapered 1
7 Plate, Wear Pad Mounting Options: 1
3538771 600A
3538247 600AJ
8 4640862 Valve Block Assembly (No Service Parts Available -
Replace Complete Assembly) 1
9 2220885 Plug, O-Ring 2
10 3931516 Capscrew, Socket Head 5/16in-18NC x 1in 8
11 3931448 Capscrew, Socket Head 1/4in-20NC x 3in 4
12 Use 2901278 Ring, Wear 2
13 Use 2901278 Seal 1
14 Use 2901278 O-Ring 1
15 Use 2901278 O-Ring 1
16 Use 2901278 Ring, Wear 1
17 Use 2901278 O-Ring 1
18 Use 2901278 Ring, Back-Up 1
19 Use 2901278 Seal, Rod 1
20 Use 2901278 Wiper 1
21 Use 2901278 Ring, Back-Up 2
22 0100038 Primer, Locking A/R
23 0100011 Compound, Locking A/R
24 3340608 Pad, Wear 2
25 0641604 Bolt 3/8in-16NC x 1/2in 4
26 4751600 Flatwasher 3/8in Regular 4
27 Not Used
28 0630535 Bolt 1/4in-20NC x 1-1/8in 3
29 to 50 Not Used
51 2901278 Seal Kit (Includes Items 12-21) 1
