SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
.
FIGURE 2-19. HOODS INSTALLATIONS - WITHOUT NOISE REDUCTION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0255407 HOODS INSTALLATION Ref. 3
1 2680423 Hood - Engine Side (Includes Items 9,14,15 and 35) 1
2 Use 1671243 Hood - Tank Side (was p/n 2680424) 1
3 4845203 Mount - Tank Side 1
4 4845200 Mount - Engine Side 1
5 0902237 Bracket, Latch - Engine Side (Prior to S/N 0300027349 Only) 1
6 0902242 Bracket, Latch - Tank Side 1
7 4160143 Spring, Gas (Prior to S/N 0300027329) 2
4160152 Spring, Gas (S/N 0300027329 to S/N 0300069000) 2
8 0940071 Bumper 4
9 2940088 Latch, Hood (Part of Item 2 and 51) 2
10 2680434 Spacer, Hood (Tank Side) 1
11 2680433 Spacer, Hood (Engine Side) 1
12 0100011 Compound, Locking A/R
13 0902219 Bracket, Bumper 1
14 3960462 Trim (Part of Item 2 and 51) 11ft/3.4m
15 3960447 Trim (Part of Item 2 and 51) 55in/1.4m
16 0630507 Bolt, Carriage 1/2in-13NC x 1-1/4in 8
17 0641608 Bolt 3/8in-16NC x 1in 12
18 4751800 Flatwasher 1/2in Regular 8
19 4751600 Flatwasher 3/16in Regular 48
20 4751500 Flatwasher 5/16in Regular 4
21 3311805 Locknut 1/2in-13NC 8
22 3311605 Locknut 3/8in-16NC 23
23 3311505 Locknut 5/16in-18NC 2
24 4845194 Outlet, Exhaust 1
25 0721006 Bolt #10-24NC x 3/4in 4
26 4751000 Flatwasher #10 Regular 4
27 4761000 Lockwasher #10 4
28 3311001 Bolt #10-24NC 4
29 3900232 Bolt, Button Head 3/8in-16NC x 1in 11
30 1670770 Cover, Turntable - Steel (Prior to S/N 0300027941) 1
1670767 Cover, Turntable - Polyethylene (S/N 0300027941 to
S/N 0300069000) 1
31 0641404 Bolt 1/4in-20NC x 1/2in 6
32 4751400 Flatwasher 1/4in Regular 6
33 0641606 Bolt 3/8in-16NC x 3/4in 2
34 4740076 Washer, Fender 2
35 3960389 Seal (Part of Item 2 and 51) 6.3ft/1.9m
36 3960418 Seal 6.5ft/2m
37 0940049 Bumper (S/N 0300027349 to S/N 0300069000) 1
38 0902313 Bracket, Latch - Engine Side (S/N 0300027349 to
S/N 0300069000) 1
39 3311601 Nut 3/8in-16NC 3
