SECTION 6 - JLG CONTROL SYSTEM
3121287 – JLG Lift – 6-53
CANBUS FAILURE – EXCESSIVE
CANBUS ERRORS 6613 More than 22 error frames per second for 4 seconds or more than 500
Buss Off conditions since last power cycle. No functions are inhibited. Cycle power to clear the fault.
CANBUS FAILURE – TCU MOD-
ULE 6622 MACHINE SETUP  CLEARSKY = YES
No CAN2 messages are received from the TCU module for more than
30 seconds
No functions are inhibited. CAN messages are received
from the TCU module.
REMOTE CONTRACT MANAGE-
MENT OVERRIDE – ALL FUNC-
TIONS IN CREEP 681 MACHINE SETUP  CLEARSKY = YES
Value set by ClearSky TCU
Puts the machine into Creep
and locks into Transport Cleared by ClearSky TCU
CHASSIS TILT SENSOR NOT
CALIBRATED 813 The tilt sensor has not been calibrated The Ground Module reports a
faulted chassis tilt angle of 90
degrees Calibrate the Tilt sensor to clear
the fault
CHASSIS TILT SENSOR OUT OF
RANGE 814 Fault CHASSIS TILT SENSOR NOT CALIBRATED (813) is not present and
Tilt sensor measurement greater than 19º for 4 seconds. Note: Not to
be reported during Tilt Sensor calibration. No additional action required
beyond Tilted requirements
specified above. Ground Mod-
ule reports 90° angle. Tilt sensor reads less than 19º.
CHASSIS TILT SENSOR DIS-
AGREEMENT 815 The Ground Module detects one of the following conditions:
If a Drive, Steer, or Boom function is active or if the engine is cranking
or if the primary raw Tilt Sensor readings greater than ±10 º then: if
the two ground board tilt sensors disagree by more than or equal to 3
degrees for either the X axis or the Y axis for longer than 5 seconds
then the fault will be logged.
If no Drive, Steer, or Boom functions are active and the engine is not
cranking or the primary raw Tilt Sensor readings are less than ±10 º
then: if the two ground board tilt sensors disagree by more than or
equal to 1 degree for either the X axis or the Y axis for longer than 3
seconds then the fault will be logged.
Note: This fault is not reported if DTC 814 is active.
The Ground Module reports a
faulted chassis tilt angle of 90
degrees Cycle power to clear the fault.
LSS CELL #1 ERROR 821 MACHINE SETUP  LOAD SYSTEM is not set = NO
The Ground Module detects that LSS is reporting error with Cell #1
Ground Module to assume Plat-
form Load State = Overloaded CAN messages are received
from the LSS module.
LSS CELL #2 ERROR 822 MACHINE SETUP  LOAD SYSTEM is not set = NO
The Ground Module detects that LSS is reporting error with Cell #2
Ground Module to assume Plat-
form Load State = Overloaded CAN messages are received
from the LSS module.
LSS CELL #3 ERROR 823 MACHINE SETUP  LOAD SYSTEM is not set = NO
The Ground Module detects that LSS is reporting error with Cell #3
Ground Module to assume Plat-
form Load State = Overloaded CAN messages are received
from the LSS module.
LSS CELL #4 ERROR 824 MACHINE SETUP  LOAD SYSTEM is not set = NO
The Ground Module detects that LSS is reporting error with Cell #4.
Ground Module to assume Plat-
form Load State = Overloaded CAN messages are received
from the LSS module.
LSS HAS NOT BEEN CALI-
BRATED 825 MACHINE SETUP  LOAD SYSTEM is not set = NO
The load sensor has not been calibrated
Ground Module to assume Plat-
form Load State = Overloaded CAN messages are received
from the LSS module.
RUNNING AT CREEP – PLAT-
FORM OVERLOADED 826 Machine Setup  LOAD SYSTEM = WARN ONLY
The platform is Overloaded
Ground mode is active with Emergency Descent mode not active or
Platform mode is active
Refer to Table 6-6, Overload
Variations for machine
response. Not all of the trigger conditions
are met
Table 6-5. Fault Code Troubleshooting Information
Help Message DTC Condition Producing DTC
Control System Response or
Machine Condition
Corrective Action/
Operational Requirement
for Function Movement
and/or to Clear Fault
