SECTION 6 - JLG CONTROL SYSTEM
6-22 – JLG Lift – 3121287
FUEL CUTOUT:
8*
1
2
3
4
ONE RESTART: One restart with limited run time when near Empty.
ENGINE STOP: No starting permitted when near Empty.
NONE
RESTART: Restarts allowed with limited run time when near Empty 4
* This menu item is visible only if Engine = Kubota D1105
TILT:
9*
1
2
3
4
5
6
5 DEGREES: Reduces the maximum speed of all boom functions to creep when tilted more than 5 degrees
and above elevation; also reduces drive speed to creep.
4 DEGREES: Reduces the maximum speed of all boom functions to creep when tilted more than 4 degrees
and above elevation; also reduces drive speed to creep.
3 DEGREES: Reduces the maximum speed of all boom functions to creep when tilted more than 3 degrees
and above elevation; also reduces drive speed to creep.
5 DEGREES + CUT: Reduces the maximum speed of all boom functions to creep when tilted more than 5
degrees and above elevation; also disallows tower lift up, drive, telescope out and lift up.
4 DEGREES + CUT: Reduces the maximum speed of all boom functions to creep when tilted more than 4
degrees and above elevation; also disallows tower lift up, drive, telescope out and lift up.
3 DEGREES + CUT: Reduces the maximum speed of all boom functions to creep when tilted more than 3
degrees and above elevation; also disallows tower lift up, drive, telescope out and lift up.
1
* Certain market selections will limit tilt options and alter default setting.
Note: Any of the selections above will light the tilt lamp when a tilted condition occurs and will sound the platform alarm when the machine is also above elevation.
JIB:
10*
1
2
NO: No jib installed.
YES: Jib installed which has up and down movements only. 2
* This menu item not visible.
4 WHEEL STEER:
11*
1
2
NO: No four-wheel steer installed.
YES: Four-wheel steer installed.
1
* This item not visible.
SKYGUARD:
12
1
2
NO: No SkyGuard system installed.
SKYGUARD: SkyGuard system installed.
1
GEN SET/WELDER:
13
1
2
No generator installed
BELT DRIVE: Belt driven setup.
1
GEN SET CUTOUT:
14*
1
2
MOTION ENABLED: Motion enabled when generator is ON.
MOTION CUTOUT: Motion cutout in platform mode only.
1
* Only visible if Gen Set / Welder = Belt Drive.
Table 6-2. Machine Configuration Programing Information
