SECTION 6 - JLG CONTROL SYSTEM
6-28
– JLG Lift –
3121287
3374
GEN SET/WELDER - OPEN CIRCUIT
3375
GEN SET/WELDER - SHORT TO BATTERY
3376
HEAD TAIL LIGHT - SHORT TO GROUND
3377
HEAD TAIL LIGHT - OPEN CIRCUIT
3378
HEAD TAIL LIGHT - SHORT TO BATTERY
3379
HOUR METER - SHORT TO GROUND
3382
PLATFORM LEVEL UP VALVE - SHORT TO GROUND
3383
PLATFORM LEVEL UP VALVE - OPEN CIRCUIT
3384
PLATFORM LEVEL UP VALVE - SHORT TO BATTERY
3388
PLATFORM LEVEL DOWN VALVE - SHORT TO GROUND
3389
PLATFORM LEVEL DOWN VALVE - OPEN CIRCUIT
3390
PLATFORM LEVEL DOWN VALVE - SHORT TO BATTERY
3394
PLATFORM ROTATE LEFT VALVE - SHORT TO GROUND
3395
PLATFORM ROTATE LEFT VALVE - OPEN CIRCUIT
3396
PLATFORM ROTATE LEFT VALVE - SHORT TO BATTERY
3397
PLATFORM ROTATE RIGHT VALVE - SHORT TO GROUND
3398
PLATFORM ROTATE RIGHT VALVE - OPEN CIRCUIT
3399
PLATFORM ROTATE RIGHT VALVE - SHORT TO BATTERY
33100
JIB LIFT UP VALVE - SHORT TO GROUND
33101
JIB LIFT UP VALVE - OPEN CIRCUIT
33102
JIB LIFT UP VALVE - SHORT TO BATTERY
33103
JIB LIFT DOWN VALVE - SHORT TO GROUND
33104
JIB LIFT DOWN VALVE - OPEN CIRCUIT
33105
JIB LIFT DOWN VALVE - SHORT TO BATTERY
33106
TOWER LIFT UP VALVE - SHORT TO GROUND
33107
TOWER LIFT UP VALVE - OPEN CIRCUIT
33109
TOWER LIFT DOWN VALVE - SHORT TO GROUND
33110
TOWER LIFT DOWN VALVE - OPEN CIRCUIT
33118
SWING RIGHT VALVE - SHORT TO GROUND
33119
SWING RIGHT VALVE - OPEN CIRCUIT
33120
TELESCOPE IN VALVE - SHORT TO BATTERY
33122
SWING LEFT VALVE - SHORT TO GROUND
33123
TELESCOPE OUT VALVE - SHORT TO BATTERY
33130
THROTTLE ACTUATOR - SHORT TO GROUND
33131
THROTTLE ACTUATOR - OPEN CIRCUIT
33132
THROTTLE ACTUATOR - SHORT TO BATTERY
33182
LIFT VALVES - SHORT TO BATTERY
33186
TELESCOPE OUT VALVE - OPEN CIRCUIT
33188
TELESCOPE OUT VALVE - SHORT TO GROUND
33189
TELESCOPE IN VALVE - OPEN CIRCUIT
33190
TELESCOPE IN VALVE - SHORT TO GROUND
33279
GLOWPLUG - OPEN CIRCUIT
33280
GLOWPLUG - SHORT TO BATTERY
Table 6-4. Fault Code List
DTC
Text
