SECTION 1 - SPECIFICATIONS
3121287 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 OPERATING SPECIFICATIONS
Operating Specifications
Dimensional Data
Capacities
Table 1-1. Operating Specifications
Capacity: Unrestricted:
ANSI
ANSI Export
500 lbs. (227 kg)
500 lbs. (227 kg)
Maximum Travel Grade, stowed
Position (Gradeability) 45%
Maximum Travel Grade, stowed
Position (Side Slope) 5°
Drive Speed - Stowed 2.8 mph (4.5 kph)
Elevated Drive Speed 0.75 mph (1.2 kph)
Gross Machine Weight - Approximate 23300 lbs. (10568 kg)
Ground Bearing Pressure 83 psi (5.83 kg/cm
2
)
System Voltage 12V DC
Maximum Main Relief Hyd. Pressure 3000 psi (207 Bar)
Table 1-2. Dimensional Data
Turning Radius (Inside Left Turn) 12’ 9" (3.89 m)
Turning Radius (Inside Right Turn) 12’ 11" (3.93 m)
Turning Radius (Outside Left Turn) 22’ 10" (6.95 m)
Turning Radius (Outside Right Turn) 22’ 6" (6.85 m)
Machine Height (stowed) 9’ (2.76 m)
Machine Height (storage) 8’ 2" (2.5 m)
Machine Length (stowed) 38’ 8" (11.85 m)
Horizontal Reach 58’ 5" (17.8 m)
Machine Width (Normal Operation) 8’ 2" (2.49 m)
Machine Width (Shipping) 7’ 1" (2.2 m)
Wheel Base 9’ 6" (2.9 m)
Platform Height 80’ 5" (24.5 m)
Platform Height w/LSS 80’ 6" (24.5 m)
Ground Clearance 11.2" (28.5 cm)
Table 1-3. Capacities
Hydraulic Oil Tank (to Full Level) 32.5 Gal. (123 L)
Drive Hub
* 20.5 oz. (0.6 L)
*
Drive hubs should be one half full of lubricant.
