SECTION 6 - JLG CONTROL SYSTEM
3121287 – JLG Lift – 6-27
2371 FUNCTION PROBLEM - JIB LIFT DOWN PERMANENTLY SELECTED
2372 FUNCTION PROBLEM - SWING LEFT PERMANENTLY SELECTED
2373 FUNCTION PROBLEM - SWING RIGHT PERMANENTLY SELECTED
23104 BOOM TRANSPORT SWITCH DISAGREEMENT
23105 FUNCTION PROBLEM - TOWER LIFT UP PERMANENTLY SELECTED
23106 FUNCTION PROBLEM - TOWER LIFT DOWN PERMANENTLY SELECTED
23107 FUNCTION PROBLEM - LIFT UP PERMANENTLY SELECTED
23108 FUNCTION PROBLEM - LIFT DOWN PERMANENTLY SELECTED
23109 FUNCTION PROBLEM - TELESCOPE IN PERMANENTLY SELECTED
23110 FUNCTION PROBLEM - TELESCOPE OUT PERMANENTLY SELECTED
23111 FUNCTION PROBLEM - PLATFORM LEVEL UP PERMANENTLY SELECTED
23112 FUNCTION PROBLEM - PLATFORM LEVEL DOWN PERMANENTLY SELECTED
23113 FUNCTION PROBLEM - PLATFORM ROTATE LEFT PERMANENTLY SELECTED
23114 FUNCTION PROBLEM - PLATFORM ROTATE RIGHT PERMANENTLY SELECTED
259 MODEL CHANGED - HYDRAULICS SUSPENDED - CYCLE EMS
2513 GENERATOR MOTION CUTOUT ACTIVE
2514 BOOM PREVENTED - DRIVE SELECTED
2516 DRIVE PREVENTED - ABOVE ELEVATION
2517 DRIVE PREVENTED - TILTED & ABOVE ELEVATION
2518 DRIVE PREVENTED - BOOM SELECTED
331 BRAKE - SHORT TO BATTERY
332 BRAKE - OPEN CIRCUIT
334 LIFT UP VALVE - OPEN CIRCUIT
335 LIFT DOWN VALVE - SHORT TO BATTERY
336 LIFT DOWN VALVE - OPEN CIRCUIT
3311 GROUND ALARM - SHORT TO BATTERY
3352 LP LOCK - SHORT TO GROUND
3353 LP LOCK - OPEN CIRCUIT
3354 LP LOCK - SHORT TO BATTERY
3355 LP START ASSIST - SHORT TO GROUND
3356 LP START ASSIST - OPEN CIRCUIT
3357 LP START ASSIST - SHORT TO BATTERY
3358 MAIN DUMP VALVE - SHORT TO GROUND
3359 MAIN DUMP VALVE - OPEN CIRCUIT
3360 MAIN DUMP VALVE - SHORT TO BATTERY
3361 BRAKE - SHORT TO GROUND
3362 START SOLENOID - SHORT TO GROUND
3363 START SOLENOID - OPEN CIRCUIT
3364 START SOLENOID - SHORT TO BATTERY
3365 STEER DUMP VALVE - SHORT TO GROUND
3366 STEER DUMP VALVE - OPEN CIRCUIT
3367 STEER DUMP VALVE - SHORT TO BATTERY
3373 GEN SET/WELDER - SHORT TO GROUND
Table 6-4. Fault Code List
DTC Text
