SECTION 6 - JLG CONTROL SYSTEM
3121287 – JLG Lift – 6-21
Table 6-2. Machine Configuration Programing Information
Configuration Label/Digit Number Description
Default
Number
The machine configuration must be completed before any personality settings can be changed. Changing the personality settings first and then changing the model number of the
machine configuration will cause the personality settings to return to default.
MODEL NUMBER:
1
0
1
2
3
Visible only on a Non-Configured UGM
340AJ
18RS
24RS
1
MARKET:
2
1
2
3
4
5
6
ANSI USA
ANSI EXPORT
CSA
CE
AUSTRALIA
JAPAN
1
ENGINE:
3
1
2
3
KUBOTA D1105132
DUAL FUEL ECM: GM/PSI 0.97L Duel Fuel (Tier 3)
Deutz EMR2
1
FLYWHEEL TEETH:
4*
1 98 TEETH: 98 flywheel teeth. 1
* This menu item is not visible
GLOW PLUG:
5*
1
2
NO GLOW PLUGS: No glow plugs installed.
IN-CYLINDER: Glow plugs installed in each cylinder. 2
* This menu item is not visible
STARTER LOCKOUT:
6*
1
2
DISABLED: Automatic pre-glow time determined by ambient air temperature; engine start can be
attempted at any time during pre-glow.
ENABLED: Automatic pre-glow time determined by ambient air temperature; engine start is NOT permitted
until pre-glow is finished.
1
* This menu item is visible only if Engine = Kubota D1105
ENGINE SHUTDOWN:
7
1
2
DISABLED: No engine shutdown.
ENABLED: Shutdown engine when coolant temperature is greater than 110 deg. C or the oil pressure is less
than 8 PSI. 2
