SECTION 1 - SPECIFICATIONS
3121287
– JLG Lift –
1-3
Major Component Weights
DO NOT REPLACE ITEMS CRITICAL TO STABILITY WITH ITEMS OF DIFFERENT
WEIGHT OR SPECIFICATION (FOR EXAMPLE: BATTERIES, FILLED TIRES, PLAT-
FORM) DO NOT MODIFY UNIT IN ANY WAY TO AFFECT STABILITY.
1.2
FUNCTION SPEEDS
Notes:
1.
Personality settings can be adjusted anywhere within
the adjustment range in order to achieve optimum
machine performance.
2.
Stop watch should be started with the function move-
ment, not with actuation of the joystick or switch.
3.
All speed tests are run from the platform, except those
specifically designated to be run in Ground Mode.
4.
The platform speed control knob must be at full speed
(turned clockwise completely) unless noted.
5.
Functional speeds may vary due to cold thick hydraulic
oil. Test should be run with the oil temperature above
38° C (100° F)
6.
Drive test results reflect 39 x 15 - 22.5 Foam Filled Tires.
Table 1-7. Critical Stability Weights
Components
LBS.
KG.
Tire & Wheel (Foam-Filled)
513
233
Engine Assembly (w/tray)
1125
510
Battery
41
18.5
Chassis complete (w/swing bearing)
4950
2245
Chassis & Turntable (w/o booms)
11735
5323
Left Counterweights
907
411.5
Right Counterweights
907
411.5
Tower Boom
2013
913
Tower Link
893
405
Upright
1715
778
Main Boom Assembly
3475
1576
Platform
224
102
Platform Support
68
31
Platform Rotator
55
25
