Electrical System
9-72 3508PS, 3509PS, 3512PS, 3513PS, 4008PS, 4009PS, 4012PS, 4013PS, 4017PS, 40.8, 40.9
TRANSMISSION C
COIL – SHORT TO
GROUND 33242 1 Deactivate output J1-10
Transmission C Control Coil.
3
rd
, 2
nd
, and 1
st
will be the only
available gear selections.
Flash the “Gear Selection” symbol
on the LCD of the cabin’s display.
A TRANSMISSION configuration of
POWERSHIFT is configured and a
GEAR SELECTION of 4F/3R is
configured and the UGM detects a
short to ground at this output.
Power cycled.
TRANSMISSION B
COIL –
OPEN CIRCUIT 33243 1 Deactivate output J2-32
Transmission B Control Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display.
A TRANSMISSION configuration of
POWERSHIFT is configured and
the UGM detects an open circuit at
this output.
Power cycled.
TRANSMISSION B
COIL – SHORT TO
BATTERY 33244 1 Deactivate output J2-32
Transmission B Control Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display.
A TRANSMISSION configuration of
POWERSHIFT is configured and
the UGM detects a short to battery
at this output.
Power cycled.
TRANSMISSION B
COIL – SHORT TO
GROUND 33245 1 Deactivate output J2-32
Transmission B Control Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display.
A TRANSMISSION configuration of
POWERSHIFT is configured and
the UGM detects a short to ground
at this output.
Power cycled.
TRANSMISSION
REVERSE COIL –
OPEN CIRCUIT 33246 1 Deactivate output J2-32
Transmission Reverse Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display.
A TRANSMISSION configuration of
HYDROSTATIC is configured and
the UGM detects an open circuit at
this output.
Power cycled.
TRANSMISSION
REVERSE COIL –
SHORT TO
BATTERY 33247 1 Deactivate output J2-32
Transmission Reverse Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display.
A TRANSMISSION configuration of
HYDROSTATIC is configured and
the UGM detects a short to battery
at this output.
Power cycled.
TRANSMISSION
REVERSE COIL –
SHORT TO
GROUND 33248 1 Deactivate output J2-32
Transmission Reverse Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display.
A TRANSMISSION configuration of
HYDROSTATIC is configured and
the UGM detects a short to ground
at this output.
Power cycled.
TRANSMISSION A
COIL –
OPEN CIRCUIT 33249 1 Deactivate output J2-33
Transmission A Control Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display.
A TRANSMISSION configuration of
POWERSHIFT is configured and
the UGM detects an open circuit at
this output.
Power cycled.
TRANSMISSION A
COIL – SHORT TO
BATTERY 33250 1 Deactivate output J2-33
Transmission A Control Coil.
Flash the “Gear Selection” and the
“Drive Direction” symbols on the
LCD of the cabin’s display.
A TRANSMISSION configuration of
POWERSHIFT is configured and
the UGM detects a short to battery
at this output.
Power cycled.
Message Fault
Code
Indicators Other Actions Taken Trigger for Fault Latch Until
