Electrical System
9-6 3508PS, 3509PS, 3512PS, 3513PS, 4008PS, 4009PS, 4012PS, 4013PS, 4017PS, 40.8, 40.9
9.4.2 Personalities
9.4.3 Calibrations
Function Description Range Default Value
Main Lift Allows the owner to adjust the Max Lift Up & Max Lift
Down function speeds 900-2500 mA 1550 mA
Soft Lift Allows the owner to adjust the derate value when the
boom enters the soft lift zone 0-90% 40%
Telescope Allows the owner to adjust the Max Tele In & Max Tele Out
function speeds 900-2500 mA 1550 mA
Fork Tilt Allows the owner to adjust the Max Fork Tilt Up & Max
Fork Tilt Down function speeds 900-2500 mA 1200 mA
Platform
Level Allows the owner to adjust the Max Platform Level Up &
Max Platform Level Down function speeds 800-900 mA (Up)
800-870 mA (Down)
900 mA (Up)
870 mA (Down)
Platform
Rotate Allows the owner to adjust the Max Platform Left & Max
Platform Right function speeds 720-940 mA (Right)
720-970 mA (Left)
940 mA (Right)
970 mA (Left)
Stabilizers Allows the owner to adjust the Max Stabilizer Up & Max
Stabilizer Down function speeds 600-2500 mA 1600 mA
Frame
Level Allows the owner to adjust the Max Frame Level Left &
Max Frame Level Right function speeds 1000-2500 mA 1000 mA
Aux.
Function 1 Allows the owner to adjust the Accel, Decel, and Max
Function A & Max Function B function speeds 1100-2500 mA 1550 mA
Aux.
Function 2 Allows the owner to adjust the Accel, Decel, and Max
Function A & Max Function B function speeds 1100-2500 mA 1550 mA
Aux.
Momentary Allows the owner to adjust the Max Momentary Aux A &
Max Momentary Aux B function speeds 0-1800 mA 1100 mA
Bucket
Mode Allows the owner to adjust the Max Bucket Up & Max
Bucket Down function speeds 1200-2500 mA 1550 mA
Function Description
Boom Angle Allows the owner to calibrate the boom angle sensor if it is replaced. Refer to Section 9.14.7,
“Boom Angle Sensor.”
