SECTION 3 - ATTACHMENTS
31200727
G10-43A,G9-43A,G6-42A
61
FIGURE 3-4. 50IN SIDE SHIFT CARRIAGE
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001142790
1
50IN SIDE SHIFT CARRIAGE, (includes all items)
B
1
N.S.S.
1
WELDMENT
2
70024535
1
SHAFT
3
70024536
2
COLLAR
4
70024123
2
ADAPTER, 90, (includes o-ring)
5
70024537
2
HOSE ASSEMBLY
6
N.S.S.
1
SN PLATE
7
70024538
3
WARNING DECAL
8
N.S.S.
1
WELDMENT
9
Ref
50IN SIDE SHIFT CYLINDER, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
10
70024540
4
BUSHING
11
70024541
8
CIRCLIP
12
70024542
4
GREASE FITTING
13
70024543
4
RETAINER
14
70024544
2
SHAFT
15
N.S.S.
1
SN PLATE
16
70024551
4
LOCKWASHER, 16mm
17
70024552
4
HEX HD CAPSCREW, M16X45, GR10.9
18
70024553
2
HEX NUT, M16, GR8
19
70024554
2
HEX HD CAPSCREW, M16X100, GR10.9
20
70022997
8
LOCKWASHER, 12mm
21
70024555
8
HEX HD CAPSCREW, M12X35, GR10.9
22
91403413
1
FEMALE QUICK DISCONNECT
23
8420055
1
DUST PLUG
24
91403414
1
MALE QUICK DISCONNECT
25
8420053
1
DUST CAP
26
70024550
2
ADAPTER, 90, (includes o-ring)
K1
70024545
1
HYDRAULIC REPAIR KIT, (includes items 5 & 22 thru 26)
B
K2
70024546
1
RETAINER KIT, (includes items 13, 20 & 21)
B
