SECTION 9 - HYDRAULIC COMPONENTS
31200727
G10-43A,G9-43A,G6-42A
359
FIGURE 9-23. MAIN CONTROL VALVE G9-43A
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001105611
1
MAIN CONTROL VALVE, (G9-43A, if not equipped with tilt on
joystick), (includes items 1 thru 24)
F
1
70023311
1
INLET SECTION ASSY
2
70024192
1
SPOOL SECTION ASSY, LIFT
3
70024193
1
SPOOL SECTION ASSY, EXTEND/RETRACT
4
70024194
1
SPOOL SECTION ASSY, FRAME LEVEL
5
70024195
1
SPOOL SECTION ASSY, TILT
6
70024196
1
SPOOL SECTION ASSY, AUX
7
70024197
1
OUTLET SECTION ASSY
8
70022008
3
SHUT-OFF PLUG ASSY
9
70022010
5
RELIEF VALVE, 280 BAR
10
70022011
2
RELIEF VALVE, 185 BAR
11
70024198
1
DRAIN REGULATOR ASSY
12
70022016
4
END MECHANISM PO KIT
13
70023318
3
SEAL PLATE GROUP
14
70023319
3
END MECHANISM KIT
15
70023320
3
TIE ROD, METRIC
16
70022019
6
TIE ROD NUT, METRIC
17
70022020
1
INLET SEAL KIT
18
70024199
2
PO SECTION SEAL KIT
19
70024200
3
MANUAL SECTION SEAL KIT
20
8036508
1
DRAIN REGULATOR SEAL KIT
21
70022023
3
SHUT-OFF PLUG/FULL FLOW RV SEAL KIT
22
70022025
7
O-RING
23
70024201
2
O-RING
24
70024202
1
O-RING
108
8304042
4
ROUND HD CARRIAGE BOLT, 3/8-16X1-1/2, (not shown)
109
4761600
4
LOCKWASHER, 3/8, (not shown)
110
88501006
4
HEX NUT, 3/8-16, (not shown)
115
4751600
4
WASHER, 3/8, (not shown)
