SECTION 9 - HYDRAULIC COMPONENTS
31200727
G10-43A,G9-43A,G6-42A
331
FIGURE 9-11. COMPENSATION CYLINDER G6-42A (SN 0160057586 to Present)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001152467
1
COMPENSATION CYLINDER, (G6-42A), (includes items 1 thru 13)
A
1
70025963
1
BARREL
2
70025964
1
ROD ASSY
3
70025952
1
PISTON ASSY
4
70025953
1
GLAND
5
70025954
1
BUSHING
6
70025955
2
BUSHING
7
70025956
1
LOCKING SCREW
8
70025965
2
BLANKING PLUG
9
70023101
1
SNAP RING
10
70025966
2
GREASE FITTING
11
70024020
3
GREASE FITTING
12
70025957
1
GREASE NIPPLE
13
70025614
1
BALL
14
Kit K1 or K3
1
PISTON HEAD BEARING RING
15
Kit K1 or K3
1
PISTON SEAL
16
Kit K1 or K3
1
O-RING
17
Kit K2 or K3
1
BACK-UP RING
18
Kit K2 or K3
1
ROD SEAL
19
Kit K1 or K3
1
O-RING
20
Kit K2 or K3
1
WIPER
K1
Kit K2 or K3
1
SEAL KIT
