SECTION 8 - HYDRAULIC CIRCUITS
31200727 G10-43A,G9-43A,G6-42A 289
FIGURE 8-10. OUTRIGGER CONTROLLER
ITEM PART NUMBER QTY DESCRIPTION REV
1 0641408 4 HEX HD CAPSCREW, 1/4-20X1, GR5
2 0641508 3 HEX HD CAPSCREW, 5/16-18X1, GR5
3 2110406 4 ADAPTER, CONNECTOR, (includes o-ring)
5 2130606 1 ADAPTER, 90, (includes o-ring)
6 2170206 1 ADAPTER, 90, (includes o-ring)
7 3311405 4 HEX LOCKNUT, 1/4-20
10 4711400 4 WASHER, 1/4
11 4711500 3 WASHER, 5/16
17 Ref CONTROLLER, (See CONTROLS SECTION for Breakdown)
18 1001090021 1 BRACKET
104 2130406 4 ADAPTER, 90, (includes o-ring)
107 Ref OUTRIGGER VALVE ASSY, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
211 0641520 3 HEX HD CAPSCREW, 5/16-18X2-1/2, GR5
232 4711500 3 WASHER, 5/16
318 Ref HOSE ASSY, (See BOOM JOYSTICK CIRCUIT for Breakdown)
323 1001136489 4 HOSE ASSY
