SECTION 7 - CONTROLS
31200727
G10-43A,G9-43A,G6-42A
235
FIGURE 7-1. BRAKE
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001091173
Ref
BRAKE INSTALLATION, (not available to order, see items 1 thru 19
for service)
F
1
Ref
BRAKE VALVE, (See HYDRAULIC COMPONENTS SECTION for
Breakdown)
2
1001091118
1
BRACKET
3
1001090741
1
PEDAL
4
91476031
1
PIN
5
0641608
1
HEX HD CAPSCREW, 3/8-16X1, GR5
6
4761600
1
LOCKWASHER, 3/8
7
0701014
4
HEX HD CAPSCREW, M10X30, GR8.8
8
4832000
4
LOCKWASHER, 10mm
10
2221257
1
STRAIGHT FITTING, (includes o-ring)
11
8770258
1
STRAIGHT FITTING, (includes o-ring)
13
2172106
2
ADAPTER, 90, (swivel nut)
14
2221244
1
REDUCER ADAPTER, (includes o-ring)
15
91513180
2
ACTUATOR
16
91511145
1
TIE BAR
17
2144605
3
STRAIGHT FITTING, (includes o-ring)
19
3020039
AR
MOLY PASTE
101
0641508
4
HEX HD CAPSCREW, 5/16-18X1
102
4761500
4
LOCKWASHER, 5/16
103
4751500
4
WASHER, 5/16
