SECTION 9 - HYDRAULIC COMPONENTS
31200727
G10-43A,G9-43A,G6-42A
343
FIGURE 9-17. SIDE TILT CARRIAGE CYLINDER
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001090134
1
SIDE TILT CARRIAGE CYLINDER, (includes items 1 thru 8)
B
1
70022038
1
BARREL ASSY
2
70022039
1
ROD ASSY
3
70022040
1
PISTON
4
70024002
1
ROD BEARING
5
90022230
1
HEX NUT
6
7029760
1
CAPSCREW
7
4640438
2
CHECK VALVE
7
2900770
1
SEAL KIT
8
91044080
2
GREASE FITTING
101
3423307
2
CYLINDER PIN
102
3841203
2
KEEPER
103
0681810
2
HEX HD CAPSCREW, 1/2-13X1-1/4, GR8
K1
70022041
1
SEAL KIT, (includes kits K2 & K3)
K2
70022042
1
PISTON SEAL KIT
K3
70022043
1
ROD BEARING SEAL KIT
