SECTION 9 - HYDRAULIC COMPONENTS
31200727 G10-43A,G9-43A,G6-42A 337
FIGURE 9-14. FRAME LEVEL CYLINDER G6-42A
ITEM PART NUMBER QTY DESCRIPTION REV
1001140444 1 FRAME LEVEL CYLINDER, (G6-42A), (includes items 1 thru 19) A
1 Kit K1 AND K3 1 BACK-UP RING
2 Kit K1 AND K3 1 BUFFER RING
3 Kit K1 AND K3 1 BUSHING
4 Kit K2 3 BUSHING
5 Kit K1 AND K3 1 O-RING
6 Kit K1 1 O-RING
7 Kit K4 1 PISTON
8 Kit K1 AND K4 1 PISTON SEAL
9 Kit K3 1 RETAINER
10 Kit K2 1 ROD
11 Kit K2 1 ROD END
12 Kit K1 AND K3 1 ROD SEAL
13 Kit K4 1 SET SCREW
14 70025936 1 BARREL
15 Kit K1 AND K4 2 WEAR RING
16 Kit K1 AND K3 1 WIPER
K1 70025937 1 SERVICE KIT
K2 70025938 1 ROD ASSY KIT
K3 70025939 1 RETAINER SUB ASSY KIT
K4 70025940 1 PISTON SUB ASSY KIT
